REVISION F
((No OF POS / 26) x .840[21.34]) + .600[15.24] REF
DO NOT
SCALE FROM
THIS PRINT
((No OF POS / 26) x .840[21.34]) + .210[5.33] REF
.083 2.10
REF
.8400 21.336 (TYP)
C
QFS-XXX-XX-XX-D-EM2-XXX-XX
No OF POSITIONS
-026, -052, -078,
-104, *-130
(PER ROW)
LEAD STYLE
-01
PLATING SPECIFICATION
-SL: SELECTIVE LIGHT GOLD
(USE C-210-01-SL)
-S: SELECTIVE GOLD (USE C-210-01-S)
-L: LIGHT GOLD
(USE C-210-01-L)
-H: HEAVY GOLD
(USE C-210-01-H)
(ALL PLATING STYLES USE
T-1G26-01-L & WT-17-GF)
PACKAGING OPTION
-TR: TAPE AND REEL PACKAGING
(-026 & -052 WITH NO OPTIONS)
END OPTIONS
.108 2.73
25 EQ SPACES @
.0250[.635] (TYP)
"A"
02
-EM2: EDGE MOUNT
ROW SPECIFICATION
-D: DOUBLE
.320 8.13
REF
* = NOT TOOLED
"A"
01
.313 7.95
REF
.220 5.59
REF
.009 0.23
REF (TYP)
.0250 0.635 (TYP)
(((No OF POS / 26) x .840[21.34]) - .215[5.46]) .003[0.08]
1.5 MAX SWAY (TYP)
(EITHER DIRECTION)
C
QFS-052-01-XX-D-EM2 SHOWN
.140 3.56 REF (TYP)
FIG 1
.150 3.81
REF
.250 6.35
REF
.055 1.40 REF
.200 5.08
REF
.170 4.32
REF
.025 0.64
REF (TYP)
.038 0.97 REF
.050 1.27 REF
.078 1.98 REF
C
C
((No OF POS / 26) x .840[21.34]) + .480[12.19]
2 MAX SWAY
(EITHER DIRECTION)
.2075±.0025 5.27±0.06
SECTION "C"-"C"
"C"
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: .0015[0.038] MAX.
3. MINIMUM PUSHOUT FORCE: SIGNAL: .5 LB[2.22N],
GROUND & WELD TAB: 1 LB[4.45N].
4. MAX VARIANCE OF .002[0.05].
5. DIMENSION APPLIES TO GROUND PLANE & SIGNAL PINS.
6. PARTS TO BE PACKAGED IN TRAYS AS STANDARD.
"C"
.010 0.25 REF
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 2:1
INSULATOR: VECTRA E130i; COLOR: BLACK
TERMINAL & GROUND PLANE:
PHOS BRONZE
F:\DWG\MISC\MKTG\QFS-XXX-XX-XX-D-EM2-XXX-XX-MKT.SLDDRW
.0500[.635] C.L. DOUBLE ROW EDGE MOUNT SOCKET STRIP
DWG. NO.
BY:
BRATCHER 01/18/2006
QFS-XXX-XX-XX-D-EM2-XXX-XX
SHEET
1
OF
2
REVISION F
C
.0040 0.102
C
IN-PROCESS 1
.134±.005 3.41±0.13
(MEASURED CONTACT
TO CONTACT)
"B"
.008 0.20
REF
.000±.005 0.00±0.13
QFS-26-01-D-EM2-XX
T-1G26-01-L
WT-17-GF
C-210-01-XX
.058 1.47 REF
SECTION "B"-"B"
SCALE 4 : 1
IN-PROCESS 2
"B"
"D"
.147 3.73
(SEE NOTE 4)
.058±.005 1.47±0.13
(SEE NOTE 5)
C
.134 3.40
SECTION "A"-"A"
SCALE 7.5 : 1
SECTION "D"-"D"
SCALE 4 : 1
T-1G26-01-L
PROPRIETARY NOTE
"D"
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DO NOT SCALE DRAWING
SHEET SCALE: 2.5:1
.0500[.635] C.L. DOUBLE ROW EDGE MOUNT SOCKET STRIP
QFS-XXX-XX-XX-D-EM2-XXX-XX
BY:
BRATCHER 01/18/2006
DWG. NO.
F:\DWG\MISC\MKTG\QFS-XXX-XX-XX-D-EM2-XXX-XX-MKT.SLDDRW
SHEET
2
OF
2
