Surface Mount
50Ω
Operating Temperature
Storage Temperature
RF Power
DC Current
RF Transformer
350 to 1500 MHz
Features
-40°C to 85°C
-55°C to 100°C
0.25W
30mA
TC1-15G2+
Maximum Ratings
• suitable for tin/lead and RoHS solder systems
• wideband, 350 to 1500 MHz
• balanced transmission line
• good return loss
• aqueous washable
CASE STYLE: AT224-3
PRICE: $2.49 ea. QTY (20)
$1.49 ea. QTY (100)
Permanent damage may occur if any of these limits are exceeded.
+RoHS Compliant
The +Suffix identifies RoHS Compliance. See our web site
for RoHS Compliance methodologies and qualifications
and Reel
Available Tape cost
tra
at no ex
Devices/Reel
20, 50, 100, 200, 500
1000, 2000
Pin Connections
PRIMARY DOT
PRIMARY
SECONDARY DOT
SECONDARY
NOT USED
6
4
1
3
2
Applications
• PCS
• cellular
• impedance matching
• balanced amplifier
• baluns
Reel Size
7”
13”
Electrical Specifications
Ω
RATIO
FREQUENCY
(MHz)
3 dB
MHz
1
350-1500
—
INSERTION LOSS*
Outline Drawing AT224-3
* Insertion Loss is referenced to mid-band loss, 0.35 dB typ.
2 dB
MHz
350-1500
1 dB
MHz
800-1500
PC B L and Patter n
Typical Performance Data
FREQUENCY
(MHz)
Suggested L ayout,
T olerance to be within ±.002
INSERTION
LOSS
(dB)
0.46
0.56
0.71
0.86
0.59
0.60
0.48
0.38
0.43
0.50
INPUT
R. LOSS
(dB)
8.47
8.38
7.92
7.58
8.03
8.62
11.81
19.36
29.22
30.48
Outline Dimensions (
inch
)
mm
A
.150
3.81
G
.028
0.71
B
.150
3.81
H
.065
1.65
C
.150
3.81
J
.190
4.83
D
.050
1.27
K
.030
0.76
E
.030
0.76
F
.025
0.64
wt
grams
0.10
1.0
INSERTION LOSS (dB)
0.8
0.6
0.4
0.2
0.0
300
350.00
360.00
470.00
580.00
690.00
800.00
975.00
1150.00
1325.00
1500.00
INSERTION LOSS
40.0
RETURN LOSS (dB)
35.0
30.0
25.0
20.0
15.0
10.0
5.0
0.0
300
INPUT RETURN LOSS
Config. G
600
900
1200
FREQUENCY (MHz)
1500
600
900
1200
FREQUENCY (MHz)
1500
ISO 9001 ISO 14001 AS 9100
CERTIFIED
P.O. Box 350166, Brooklyn, New York 11235-0003 (718) 934-4500 Fax (718) 332-4661
The Design Engineers Search Engine
IF/RF MICROWAVE COMPONENTS
Mini-Circuits
®
For detailed performance specs
& shopping online see web site
®
Provides ACTUAL Data Instantly at
minicircuits.com
Notes: 1.
Performance and quality attributes and conditions not expressly stated in this specification sheet are intended to be excluded and do not form a part of this specification sheet.
2.
Electrical specifications
and performance data contained herein are based on Mini-Circuit’s applicable established test performance criteria and measurement instructions.
3.
The parts covered by this specification sheet are subject to
Mini-Circuits standard limited warranty and terms and conditions (collectively, “Standard Terms”); Purchasers of this part are entitled to the rights and benefits contained therein. For a full statement of the Standard
Terms and the exclusive rights and remedies thereunder, please visit Mini-Circuits’ website at www.minicircuits.com/MCLStore/terms.jsp.
REV. A
M111888
TC1-15G2+
IG/TD/CP/AM
120508
