Safety Connection Systems
Safety Wired Shorting Plug
Specifications
Coupling Nut
Connector
Connector Insert
Contacts
O–Ring
Enclosure Rating
Temperature
4-pin: epoxy-coated zinc
6-pin: nickel-plated brass
Red PVC
PUR
Brass, gold over nickel plating
Viton
IP67, NEMA 6P
-20°C to +105°C (-13°F to +221°F)
Features
• Shorting plug designed for use with safety-wired distribution
boxes
• PVC body offers good oil and chemical resistance
• Ratcheting coupling nut on 4-pin models for vibration resistance
Product Selection
Face View of Male
Rating
Configuration
Pin 1
Pin 2
2 Normally Closed
2
3
Wiring
Catalogue Number
Pin 3
Pin 4
898D-41LU-DM
1
4
Pin 1
10-30V DC
4A
1 Normally Closed,
1 Normally Open
Pin 2
Pin 3
Pin 4
Pin 1
Pin 2
5
6 4
2
3
1
NA
898D-41KU-DM
NA
2 Normally Closed,
1 Normally Open
Pin 3
Pin 4
Pin 5
Pin 6
NA
NA
898R-61MU-RM
Approximate Dimensions—mm (inches)
M12 x 1 Thread (4-pin)
1/2in UNF thread (6-pin)
15
(0.57)
50 (1.97)
Dimensions are approximate. Illustrations are not drawn to scale.
15-9
