Connection Systems
Safety Connection Systems
Safety Wired Distribution Box, Dual-Channel N.C./N.O., No Enunciation
Specifications
Body
Connector Insert
Receptacle Shell
Contacts
Cable
Cable O.D.
Enclosure Rating
Temperature
Red PBT
PBT
Nickel-plated brass
Gold-plated palladium/nickel
Oil-resistant yellow PVC jacket, (3)
18AWG, (16) 22AWG conductors
9.8mm (0.39in)
IP67, NEMA 6P
-20°C to +105°C (-13°F to +221°F)
Features
•
•
•
•
Prewired for dual-channel (one N.O./one N.C.) safety
4 or 8 safety-wired 4-pin DC micro connectors
4-pin male DC micro pigtail main connection
For use in category 2 or 3 systems per EN 954-1
Product Selection
Face View of
Female
1
5
4
3
2
Number of
Ports
4
Illuminated
Rating
Face View of
Male (1)
2
3
1
4
Cable Length—
m (inches)
Catalogue Number
898D-44KT
-DM4
No LED
8
10-30V DC
0.2 (8)
898D-48KT
-DM4
898D-41KU-DM
889D-F4ACDM-⊗
Shorting Plug for unused ports
Patchcord, straight to straight DC Micro,
⊗
= length in meters 1, 2, 3, 5, 10 standard
Approximate Dimensions—mm (inches)
107 (4.21)
107 (4.21)
101.5 (3.99)
39
(1.53)
8
6
101.5 (3.99)
54 (2.12)
4
2
33
(1.29)
39
(1.53)
22.2
(0.87)
54 (2.12)
P4
P2
P4
P2
P4
P2
P4
P4
P4
P2
P4
P2
P4
P2
33
(1.29)
Dimensions are approximate. Illustrations are not drawn to scale.
120 (4.72)
4.5
(0.17)
7
5
4.5
(0.17)
3
1
P2
P2
152 (5.98)
18
(0.7)
Wiring Diagrams
M/M Connector
Pin 3 Blue
Pin 1 Brown
Port 4
1
4
5
3
2
4
1
M/M Connector
Pin 3 Blue
Pin 1 Brown
Port 8
1
5
3
2
4
1
4
Port 3
5
3
2
4
1
5
Port 2
2
4
1
5
3
3
Port 1
2
Port 7
5
3
2
4
1
Port 2
5
3
2
4
1
5
3
Port 1
2
Pin 2 White
Pin 4 Black
Pin 4 Black
Pin 2 White
15-6
