Bayonet Channel x 3
26.50
`
0.05
12.50
D
USB 2.0 Type A
Female PCB Version
Receptacle Housing
Bayonet Locking Type
(Low Profile)
Panel Gasket
Panel Nut
(M28 x 1.5)
D
metal shell
Connection
n
1.10
n
1.10
n
28.00
`
0.05
n
1.10
n
1.10
n
1.10
DETAIL A
A
Recommended Panel Cutout
n
34
2.0
Sealed with Sealing Compound,
provides IP67 even when uncovered
(For potted version only)
C
Notes:
1. Electrical Specifications:
- Meets USB 2.0 Specification
- Contact Resistance: 30 mOhm max.
- Insulation Resistance: 1000 MOhm min. @ 100 VDC
- Current Rating: 1.5 A max. at 25
~
C
- Working Voltage: 30 V (RMS) max.
- DWV: 500 VAC/60s at sea level
- Operating Temperature: -40
~
C to +85
~
C
2. Material and Finish:
- Receptacle Housing (Low Profile): Polyester (Black), UL94 V-0
or Metallized ABS (Nickel Plated), UL94 V-0
- Panel Nut: Brass, Finish: Nickel Plated
- Panel Gasket: Silicon, Color: White
- USB Insulator: PBT, UL94 V-0, Black
- USB Metal Shell: Copper Alloy, Nickel Plated
- USB Overmold material: PBT UL94 V-0, Color: Black
- USB Contacts: Copper Alloy, Finish: 30 u" Gold min. over Nickel
- PCB: FR-4, UL94 V-0, Color: Green
3. Maximum panel thickness: 2.0 mm.
4. IP67 rated when covered or fully mated with the appropriate mating connector
5. Recommaned Mounting Panel Nut torque is 20 to 25 lb-inch
Description
34.5
18.8
HEX 32
C
6
Pin to typical USB Cable Wiring Assignment
Type A F
PCB
Pin1 --------- Pin1
Pin2 --------- Pin2
Pin3 --------- Pin3
Pin4 --------- Pin4
Shell--------- GND
Signal Name
USB Cable
---------- V
BUS
------------- Red
---------- D
-
------------- White
---------- D
+
------------- Green
---------- GND ------------ Black
---------- GND ------------ Drain Wire
Directive 2002/95/EC RoHS Compliant
THIS DRAWING MAY NOT BE COPIED OR REPRODUCED
IN ANY WAY, AND MAY NOT BE PASSED ON TO A THIRD
PARTY WITHOUT WRITTEN PERMISSION.
OWNERSHIP AND COPYRIGHT OF CONEC CORPORATION
B
B
DOT NOT ALTER CAD DRAWING BY HAND
Customer:
Approval Date
Unless otherwise specified
Tolerance
Name
Title
Part Number
17-210021
17-210031
17-210041
17-210051
0 PLC
1 PLC
2 PLC
3 PLC
ANGLES
`
0.50
`
0.38
`
0.25
`
0.10
`
3
~
Scale:
Autodesk
Inventor
Name
Vincent Ke
J. Chaudry
Dim. in mm
Material: See Notes
Title:
A
Plastic Version with USB 2.0 Type A Female PCB Version
Metallized Plastic Version with USB 2.0 Type A Female Version
Potted Plastic Version with USB 2.0 Type A Female PCB Version
Potted Metallized Plastic Version with USB 2.0 Type A Female Version
2012
Draw.
Appd.
Norm
D-old
Date
Oct. 09
Oct. 09
IP67 USB Receptacle Kit
(Low Profile)
A
DIN
with USB 2.0 Type A Female PCB Version
R
Drawing No.: 17K1A330
Part No.: SEE PART NUMBER TABLE
A3
Sheet
a
Rev.
original
Changes
Date
Name
1/1
6
5
4
3
2
1
