SR1045C: DescriptionRectifier Diode, Schottky, 1 Phase, 2 Element, 10A, 45V V(RRM), Silicon, TO-220AB, ROHS COMPLIANT, PLASTIC, TO-220, 3 PIN; CategoryDiscrete semiconductor diode; File Size26KB，2 Pages; ManufacturerRectron Semiconductor; Websitehttp://www.rectron.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

SR1045C Overview

Rectifier Diode, Schottky, 1 Phase, 2 Element, 10A, 45V V(RRM), Silicon, TO-220AB, ROHS COMPLIANT, PLASTIC, TO-220, 3 PIN

SR1045C Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Parts packaging code	TO-220AB
package instruction	ROHS COMPLIANT, PLASTIC, TO-220, 3 PIN
Contacts	3
Reach Compliance Code	compliant
ECCN code	EAR99
Other features	HIGH RELIABILITY, LOW NOISE
application	GENERAL PURPOSE
Shell connection	ANODE AND CATHODE
Configuration	SERIES CONNECTED, CENTER TAP, 2 ELEMENTS
Diode component materials	SILICON
Diode type	RECTIFIER DIODE
JEDEC-95 code	TO-220AB
JESD-30 code	R-PSFM-T3
JESD-609 code	e3
Humidity sensitivity level	1
Maximum non-repetitive peak forward current	150 A
Number of components	2
Phase	1
Number of terminals	3
Maximum operating temperature	150 °C
Maximum output current	10 A
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	FLANGE MOUNT
Peak Reflow Temperature (Celsius)	265
Certification status	Not Qualified
Maximum repetitive peak reverse voltage	45 V
surface mount	NO
technology	SCHOTTKY
Terminal surface	MATTE TIN
Terminal form	THROUGH-HOLE
Terminal location	SINGLE
Maximum time at peak reflow temperature	NOT SPECIFIED
Base Number Matches	1

Preview

Download Datasheet

View All

RECTRON

SEMICONDUCTOR

TECHNICAL SPECIFICATION

SR1020C

THRU

SR1060C

SCHOTTKY BARRIER RECTIFIER

VOLTAGE RANGE 20 to 60 Volts CURRENT 10 Amperes

FEATURES

*

Low switching noise

Low forward voltage drop

Low thermal resistance

High current capability

High switching capability

High surge capabitity

High reliability

.413 (10.5)

.374 (9.5)

.153 (3.9)

.146 (3.7)

.270 (6.9)

.230 (5.8)

.610 (15.5)

.583 (14.8)

.187 (4.7)

.148 (3.8)

.053 (1.3)

.047 (1.2)

TO-220

MECHANICAL DATA

*

Case: To-220 molded plastic

Epoxy: Device has UL flammability classification 94V-O

Lead: MIL-STD-202E method 208C guaranteed

Mounting position: Any

Weight: 2.24 grams

.108

(2.75)

.157

(4.0)

.051

(1.3)

.035 (0.9)

.028 (0.7)

.102 (2.6)

.091 (2.3)

.583 (14.8)

.531 (13.5)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

o

C ambient temperature unless otherwise specified.

Single phase, half wave, 60 Hz, resistive or inductive load.

For capacitive load, derate current by 20%.

.028 (0.7)

.020 (0.5)

.126

(3.2)

Dimensions in inches and (millimeters)

MAXIMUM RATINGS

(At T

A

= 25

o

C unless otherwise noted)

RATINGS

Maximum Recurrent Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward Rectified Current

at Derating Case Temperature

Peak Forward Surge Current 8.3 ms single half sine-wave

superimposed on rated load (JEDEC method)

Typical Thermal Resistance (Note 1)

Typical Junction Capacitance (Note 3)

Operating Temperature Range

Storage Temperature Range

SYMBOL

V

RRM

V

RMS

V

DC

I

O

I

FSM

R

θ

JC

C

J

T

J

T

STG

700

-55 to + 150

SR1020C SR1030C SR1035C SR1040C SR1045C SR1050C SR1060C UNITS

20

14

20

30

21

30

35

25

35

40

28

40

10

150

3

500

45

32

45

50

35

50

60

42

60

Volts

Amps

0

C/ W

pF

0

C

ELECTRICAL CHARACTERISTICS

(At T

A

= 25

o

C unless otherwise noted)

CHARACTERISTICS

Maximum Instantaneous Forward Voltage at 8.0A DC

Maximum Average Reverse Current

at Rated DC Blocking Voltage

@T

C

= 25 C

@T

C

= 100

o

C

o

SYMBOL

V

F

I

R

SR1020C SR1030C SR1035C SR1040C SR1045C SR1050C SR1060C UNITS

.55

10

100

.75

Volts

mAmps

2002-11

NOTES : 1. Thermal Resistance Junction to Case.

2. Suffix “A” = Common Anode.

3. Measured at 1 MHz and applied reverse voltage of 4.0 volts.
