Data Sheet
December 1999
MH005-Series Power Modules:
4.5 Vdc to 14 Vdc Input; 5 W
Features
I
Small size: 50.8 mm x 27.9 mm x 11.7 mm
(2.00 in. x 1.10 in. x 0.46 in.)
Wide 3:1 input range
Operating ambient temperature range:
–10 °C to +70 °C, no derating
High reliability
High efficiency: 73% typical
Input-to-output isolation
No external filtering required
No heat sink required
Overcurrent protection
Output overvoltage protection
PC board mountable
I
I
I
I
I
I
I
The MH005-Series Power Modules use advanced, surface-
mount technology and deliver high-quality, compact,
dc-dc conversion at an economical price.
I
I
I
Applications
I
I
I
I
UL*
1950 Recognized,
CSA
†
C22.2 No. 950-95
Certified,
VDE
‡
0805 (EN60950, IEC950) Licensed
Meets FCC Class A requirements
Distributed power architectures
Communication equipment
Computer equipment
I
*
UL
is a registered trademark of Underwriters Laboratories, Inc.
†
CSA
is a registered trademark of Canadian Standards Associa-
tion.
‡
VDE
is a trademark of Verband Deutscher Elektrotechniker e.V.
Options
I
I
Long pins: 5.8 mm ± 0.5 mm (0.230 in. ± 0.020 in.)
Metal case with case ground pin
Description
The MH005-Series Power Modules are dc-dc converters that operate over an input voltage range of 4.5 Vdc to
14 Vdc and provide precisely regulated dc outputs. The outputs are isolated from the inputs, allowing versatile
polarity configurations and grounding connections. The modules have maximum power ratings of 5 W with a
typical full-load efficiency of 73%.
The modules are PC board mountable and encapsulated in nonconductive cases. The modules are rated to full
load at 100 °C case temperature with no external filtering or heat sinking.
MH005-Series Power Modules:
4.5 Vdc to 14 Vdc Input; 5 W
Data Sheet
December 1999
Absolute Maximum Ratings
Stresses in excess of the absolute maximum ratings can cause permanent damage to the device. These are abso-
lute stress ratings only. Functional operation of the device is not implied at these or any other conditions in excess
of those given in the operations sections of the data sheet. Exposure to absolute maximum ratings for extended
periods can adversely affect device reliability.
Parameter
Input Voltage (continuous)
Operating Case Temperature
(See Thermal Considerations section.)
Storage Temperature
I/O Isolation Voltage (1 minute)
Symbol
V
I
T
C
T
stg
—
Min
—
–10
–40
—
Max
15
100
110
500
Unit
Vdc
°C
°C
Vdc
Electrical Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions.
Table 1. Input Specifications
Parameter
Operating Input Voltage
Maximum Input Current
(V
I
= 0 V to 14 V; I
O
= I
O, max
; see Figure 1.)
Inrush Transient
Input Reflected-ripple Current, Peak-to-peak
(5 Hz to 20 MHz, 500 nH source impedance,
T
A
= 25 °C; see Figure 15 and Design
Considerations section.)
Input Ripple Rejection (120 Hz)
Fusing Considerations
CAUTION: This power module is not internally fused. An input line fuse must always be used.
This encapsulated power module can be used in a wide variety of applications, ranging from simple stand-alone
operation to an integrated part of a sophisticated power architecture. To preserve maximum flexibility, internal fus-
ing is not included; however, to achieve maximum safety and system protection, always use an input line fuse. The
safety agencies require a normal-blow fuse with a maximum rating of 5 A in series with the input (see Safety Con-
siderations section). Based on the information provided in this data sheet on inrush energy and maximum dc input
current, the same type of fuse with a lower rating can be used. Refer to the fuse manufacturer’s data for further
information.
Symbol
V
I
I
I, max
i
2
t
I
I
Min
4.5
—
—
—
Typ
5
—
—
45
Max
14
2.5
0.2
—
Unit
Vdc
A
A
2
s
mAp-p
—
—
50
—
dB
2
Tyco Electronics Corp.
Data Sheet
December 1999
MH005-Series Power Modules:
4.5 Vdc to 14 Vdc Input; 5 W
Electrical Specifications
(continued)
Table 2. Output Specifications
Parameter
Output Voltage Set Point
(V
I
= 5 V; I
O
= I
O, max
; T
A
= 25 °C)
Device
MH005A
MH005B
MH005C
MH005BK
MH005CL
Output Voltage
(Over all operating input voltage,
resistive load, and temperature
conditions until end of life; see
Figures 17 and 18.)
MH005A
MH005B
MH005C
MH005BK
MH005CL
Output Regulation:
Line (V
I
= 4.5 Vdc to 14 Vdc)
Load (I
O
= I
O, min
to I
O, max
)
Temperature
(T
C
= –10 °C to +100 °C)
Output Ripple and Noise Voltage
(See Figure 16.):
RMS
Peak-to-peak (5 Hz to 20 MHz)
Symbol
V
O, set
V
O, set
V
O, set
V
O1, set
V
O2, set
V
O1, set
V
O2, set
V
O
V
O
V
O
V
O1
V
O2
V
O1
V
O2
—
—
—
Min
4.85
11.64
14.55
11.40
–11.40
14.25
–14.25
4.75
11.40
14.25
10.80
–10.80
13.50
–13.50
—
—
—
Typ
5.0
12.0
15.00
12.00
–12.00
15.00
–15.00
—
—
—
—
—
—
—
0.02
0.05
0.6
Max
5.15
12.36
15.45
12.60
–12.60
15.75
–15.75
5.25
12.60
15.75
13.20
–13.20
16.50
–16.50
0.1
0.2
1.5
Unit
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
Vdc
%V
O
%V
O
%V
O
MH005A, B, C
MH005A, B, C
MH005A, B, C
MH005A, B, C
MH005BK, CL
MH005A, B, C
MH005BK
MH005CL
MH005A
MH005B
MH005C
MH005BK
MH005CL
—
—
—
—
—
I
O
I
O
I
O
I
O1
I
O2
I
O1
I
O2
—
—
—
—
—
0.05*
0.02*
0.02*
0.01*
0.01*
0.01*
0.01*
3
15
—
—
—
—
—
—
—
—
—
—
15
50
50
200
250
1.0
0.42
0.33
0.21
0.21
0.17
0.17
mVrms
mVrms
mVp-p
mVp-p
mVp-p
A
A
A
A
A
A
A
Output Current
* At less than the minimum current, units will continue to operate; however, the single-output modules (MH005A, B, C) may exceed their output
ripple specification. The dual-output modules (MH005BK, CL) may exceed their output voltage regulation limits if the output currents are
severely imbalanced with one output sourcing less than the minimum current.
Tyco Electronics Corp.
3
MH005-Series Power Modules:
4.5 Vdc to 14 Vdc Input; 5 W
Data Sheet
December 1999
Electrical Specifications
(continued)
Table 2. Output Specifications
(continued)
Parameter
Output Current-limit Inception
(See Figures 4—9.):
V
O
= 4.5 V (~0.9 V
O, set
)
V
O
= 10.8 V (~0.9 V
O, set
)
V
O
= 13.5 V (~0.9 V
O, set
)
V
O1
or V
O2
= 10.2 V
†
V
O1
or V
O2
= 12.75 V
†
Output Current Limit
(V
I
= 5 V, T
A
= 25 °C; See Figures
4—9.):
V
O
= 1.0 V (~0.2 V
O, set
)
V
O
= 1.0 V (~0.08 V
O, set
)
V
O
= 1.0 V (~0.07 V
O, set
)
V
O1
or V
O2
= 1.0 V
V
O1
or V
O2
= 1.0 V
Output Short-circuit Current
(V
O
= 250 mV; see Figures 4—9.)
Device
Symbol
Min
Typ
Max
Unit
MH005A
MH005B
MH005C
MH005BK
MH005CL
I
O
I
O
I
O
I
O
I
O
—
—
—
—
—
1.5
0.7
0.6
0.7
0.6
2.5
1.0
0.9
1.2
1.1
A
A
A
A
A
MH005A
MH005B
MH005C
MH005BK
MH005CL
MH005A
MH005B
MH005C
MH005BK
MH005CL
MH005A
MH005B
MH005C
MH005BK
MH005CL
All
—
—
—
—
—
—
—
—
—
—
η
η
η
η
η
—
—
—
—
—
—
—
—
—
—
—
70
70
70
70
70
—
—
—
—
—
—
3.0
1.4
1.4
1.3
1.3
72
73
73
73
73
400
3.5
2.5
2.5
2.5
2.5
—
—
—
—
—
—
—
—
—
—
—
A
A
A
A
A
A
A
A
A
A
%
%
%
%
%
kHz
Efficiency
(V
I
= 5 V; I
O
= I
O, max
; T
A
= 25 °C;
see Figures 10, 11, 17, and 18.)
Switching Frequency
Dynamic Response
(½I
O
/½t = 1 A/10 µs, V
I
= 5 V,
T
A
= 25 °C; see Figures 12 and 13.):
Load Change from I
O
= 50% to 75%
of I
O, max
:
Peak Deviation
Settling Time
(V
O
< 10% peak deviation)
Load Change from I
O
= 50% to 25%
of I
O, max
:
Peak Deviation
Settling Time
(V
O
< 10% of peak deviation)
All
All
—
—
—
—
60
4
—
—
mV
ms
All
All
—
—
—
—
60
4
—
—
mV
ms
* At less than the minimum current, units will continue to operate; however, the single-output modules (MH005A, B, C) may exceed their output
ripple specification. The dual-output modules (MH005BK, CL) may exceed their output voltage regulation limits if the output curr
ents are
severely imbalanced with one output sourcing less than the minimum current.
† Output not in current limit is held at minimum load to give the worst-case (highest current level) inception point.
4
Tyco Electronics Corp.
Data Sheet
December 1999
MH005-Series Power Modules:
4.5 Vdc to 14 Vdc Input; 5 W
Electrical Specifications
(continued)
Table 3. Isolation Specifications
Parameter
Isolation Capacitance
Isolation Resistance
Min
—
10
Typ
1200
—
Max
—
—
Unit
pF
M¾
General Specifications
Parameter
Calculated MTBF (I
O
= 80% of I
O, max
; T
C
= 40 °C)
Weight
—
Min
Typ
5,000,000
—
113 (4.0)
Max
Unit
hours
g (oz.)
Feature Specifications
Unless otherwise indicated, specifications apply over all operating input voltage, resistive load, and temperature
conditions. See Feature Descriptions and Design Considerations for further information.
Parameter
Output Overvoltage Protection (clamp)
Device
MH005A
MH005B
MH005C
MH005BK
MH005CL
Symbol
V
O, clamp
V
O, clamp
V
O, clamp
V
O1, clamp
V
O2, clamp
V
O1, clamp
V
O2, clamp
Min
—
—
—
—
—
—
—
Typ
—
—
—
—
—
—
—
Max
7.0
17
19
17
–17
19
–19
Unit
V
V
V
V
V
V
V
Tyco Electronics Corp.
5
