INCHANGE Semiconductor
isc
Product Specification
isc
Silicon NPN Power Transistor
BUV22
DESCRIPTION
·Low
Collector Saturation Voltage-
: V
CE(
sat
)
= 1.0V (Max.) @I
C
= 10A
·High
Switching Speed
·High
DC Current Gain-
: h
FE
= 20(Min.) @I
C
= 10A
APPLICATIONS
·Designed
for high current, high speed, high power
applications.
Absolute maximum ratings(Ta=25
℃
)
SYMBOL
V
CBO
V
CER
V
CEX
V
CEO
V
EBO
I
C
I
CM
I
B
B
PARAMETER
Collector-Base Voltage
Collector-Emitter Voltage
R
BE
= 100Ω
Collector-Emitter Voltage
V
BE
= -1.5V
Collector-Emitter Voltage
Emitter-Base Voltage
Collector Current-Continuous
Collector Current-Peak
Base Current-Continuous
Collector Power Dissipation
@T
C
=25℃
Junction Temperature
Storage Temperature Range
VALUE
300
290
300
250
7
40
50
8
250
200
-65~200
UNIT
V
V
V
V
V
A
A
A
W
℃
℃
P
C
T
j
T
stg
THERMAL CHARACTERISTICS
SYMBOL
R
th j-c
PARAMETER
Thermal Resistance,Junction to Case
MAX
0.7
UNIT
℃/W
isc Website：www.iscsemi.cn
INCHANGE Semiconductor
isc
Product Specification
isc
Silicon NPN Power Transistor
ELECTRICAL CHARACTERISTICS
T
C
=25℃ unless otherwise specified
SYMBOL
PARAMETER
CONDITIONS
MIN
TYP.
BUV22
MAX
UNIT
V
CEO(SUS)
Collector-Emitter Sustaining Voltage
I
C
= 0.2A; I
B
= 0; L= 25mH
250
V
V
(BR)EBO
Emitter-Base Breakdown Voltage
I
E
= 50mA; I
C
= 0
7
V
V
CE
(sat)-1
V
CE
(sat)-2
V
BE
(sat)
I
CEO
Collector-Emitter Saturation Voltage
I
C
= 10A; I
B
= 1A
1.0
V
Collector-Emitter Saturation Voltage
I
C
= 20A ;I
B
= 2.5A
I
C
= 40A ;I
B
= 4A
1.5
V
Base-Emitter Saturation Voltage
1.5
V
Collector Cutoff Current
V
CE
= 200V; I
B
= 0
V
CE
= 300V;V
BE
= -1.5V
V
CE
= 300V;V
BE
= -1.5V;T
C
=125℃
V
EB
= 5V; I
C
= 0
3.0
3.0
12.0
1.0
mA
I
CEX
Collector Cutoff Current
mA
I
EBO
Emitter Cutoff Current
mA
h
FE-1
DC Current Gain
I
C
= 10A ; V
CE
= 4V
20
60
h
FE-2
f
T
DC Current Gain
I
C
= 20A ; V
CE
= 4V
10
Current-Gain—Bandwidth Product
I
C
= 2A;V
CE
= 15V, f
test
= 4MHz
8
MHz
Switching Times
μs
μs
μs
t
on
t
s
t
f
Turn-on Time
I
C
= 20A; I
B1
=-I
B2
= 2.5A;
V
CC
= 100V; R
C
= 5Ω
0.8
Storage Time
2.0
Fall Time
0.35
isc Website：www.iscsemi.cn
