MC34071,2,4,A
MC33071,2,4,A
High Slew Rate, Wide
Bandwidth, Single Supply
Operational Amplifiers
Quality bipolar fabrication with innovative design concepts are employed
for the MC33071/72/74, MC34071/72/74 series of monolithic operational
amplifiers. This series of operational amplifiers offer 4.5 MHz of gain
bandwidth product, 13 V/µs slew rate and fast setting time without the use of
JFET device technology. Although this series can be operated from split
supplies, it is particularly suited for single supply operation, since the
common mode input voltage range includes ground potential (VEE). With A
Darlington input stage, this series exhibits high input resistance, low input
offset voltage and high gain. The all NPN output stage, characterized by no
deadband crossover distortion and large output voltage swing, provides high
capacitance drive capability, excellent phase and gain margins, low open
loop high frequency output impedance and symmetrical source/sink AC
frequency response.
The MC33071/72/74, MC34071/72/73 series of devices are available in
standard or prime performance (A Suffix) grades and are specified over the
commercial, industrial/vehicular or military temperature ranges. The
complete series of single, dual and quad operational amplifiers are available
in plastic DIP and SOIC surface mount packages.
•
Wide Bandwidth: 4.5 MHz
HIGH BANDWIDTH
SINGLE SUPPLY
OPERATIONAL AMPLIFIERS
8
1
8
1
P SUFFIX
PLASTIC PACKAGE
CASE 626
D SUFFIX
PLASTIC PACKAGE
CASE 751
(SO–8)
PIN CONNECTIONS
Offset Null
Inputs
VEE
1
2
3
4
–
+
8
7
6
5
NC
VCC
Output
Offset Null
•
•
•
•
•
•
•
•
•
•
•
•
High Slew Rate: 13 V/µs
Fast Settling Time: 1.1
µs
to 0.1%
Wide Single Supply Operation: 3.0 V to 44 V
Wide Input Common Mode Voltage Range: Includes Ground (VEE)
Low Input Offset Voltage: 3.0 mV Maximum (A Suffix)
Large Output Voltage Swing: –14.7 V to +14 V (with
±15
V Supplies)
Large Capacitance Drive Capability: 0 pF to 10,000 pF
Low Total Harmonic Distortion: 0.02%
Excellent Phase Margin: 60°
Excellent Gain Margin: 12 dB
Output Short Circuit Protection
ESD Diodes/Clamps Provide Input Protection for Dual and Quad
ORDERING INFORMATION
Op Amp
Function
Single
Device
MC34071P, AP
MC34071D, AD
MC33071P, AP
MC33071D, AD
Dual
MC34072P, AP
MC34072D, AD
MC33072P, AP
MC33072D, AD
Quad
MC34074P, AP
MC34074D, AD
MC33074P, AP
MC33074D, AD
Operating
Temperature Range
TA = 0° to +70°C
TA = –40° to +85°C
TA = 0° to +70°C
TA = –40° to +85°C
TA = 0° to +70°C
TA = –40° to +85°C
Package
Plastic DIP
SO–8
Plastic DIP
SO–8
Plastic DIP
SO–8
Plastic DIP
SO–8
Plastic DIP
SO–14
Plastic DIP
SO–14
Output 1
Inputs 1
VCC
Inputs 2
6
14
1
(Single, Top View)
Output 1
Inputs 1
VEE
1
2
3
4
–
+
–
+
8
7
6
5
VCC
Output 2
Inputs 2
(Dual, Top View)
14
1
P SUFFIX
PLASTIC PACKAGE
CASE 646
D SUFFIX
PLASTIC PACKAGE
CASE 751A
(SO–14)
PIN CONNECTIONS
1
2
3
4
5
+
–
–
+
1
4
–
+
14
13
Output 4
Inputs 4
12
11
VEE
Inputs 3
Output 3
2
3
+
–
10
9
8
Output 2
7
(Quad, Top View)
2–272
MOTOROLA ANALOG IC DEVICE DATA
MC34071,2,4,A MC33071,2,4,A
MAXIMUM RATINGS
Rating
Supply Voltage (from VEE to VCC)
Input Differential Voltage Range
Input Voltage Range
Output Short Circuit Duration (Note 2)
Operating Junction Temperature
Storage Temperature Range
Symbol
VS
VIDR
VIR
tSC
TJ
Tstg
Value
+44
Note 1
Note 1
Indefinite
+150
–60 to +150
Unit
V
V
V
sec
°C
°C
NOTES:
1. Either or both input voltages should not exceed the magnitude of VCC or VEE.
2. Power dissipation must be considered to ensure maximum junction temperature (TJ) is not
exceeded (see Figure 1).
Representative Schematic Diagram
(Each Amplifier)
VCC
Q3
Q1
Q2
R1
Bias
–
Inputs
+
C2
D3
Q19
Base
Current
Cancellation
Q13
Q12
D1
R5
R3
R4
Current
Limit
Q14
Q15
Q16
Q8
Q9
Q10
C1
R2
Q11
Q4
Q5
Q6
Q7
Q17
D2
R6
R7
Output
R8
Q18
VEE/Gnd
Offset Null
(MC33071, MC34071 only)
MOTOROLA ANALOG IC DEVICE DATA
2–273
MC34071,2,4,A MC33071,2,4,A
ELECTRICAL CHARACTERISTICS
(VCC = +15 V, VEE = –15 V, RL = connected to ground, unless otherwise noted. See Note 3 for
TA = Tlow to Thigh)
A Suffix
Characteristics
Input Offset Voltage (RS = 100
Ω,
VCM = 0 V, VO = 0 V)
VCC = +15 V, VEE = –15 V, TA = +25°C
VCC = +5.0 V, VEE = 0 V, TA = +25°C
VCC = +15 V, VEE = –15 V, TA = Tlow to Thigh
Average Temperature Coefficient of Input Offset Voltage
RS = 10
Ω,
VCM = 0 V, VO = 0 V,
TA = Tlow to Thigh
Input Bias Current (VCM = 0 V, VO = 0 V)
TA = +25°C
TA = Tlow to Thigh
Input Offset Current (VCM = 0 V, VO = 0V)
TA = +25°C
TA = Tlow to Thigh
Input Common Mode Voltage Range
TA = +25°C
TA = Tlow to Thigh
Large Signal Voltage Gain (VO =
±10
V, RL = 2.0 kΩ)
TA = +25°C
TA = Tlow to Thigh
Output Voltage Swing (VID =
±1.0
V)
VCC = +5.0 V, VEE = 0 V, RL = 2.0 kΩ, TA = +25°C
VCC = +15 V, VEE = –15 V, RL = 10 kΩ, TA = +25°C
VCC = +15 V, VEE = –15 V, RL = 2.0 kΩ,
TA = Tlow to Thigh
VCC = +5.0 V, VEE = 0 V, RL = 2.0 kΩ, TA = +25°C
VCC = +15 V, VEE = –15 V, RL = 10 kΩ, TA = +25°C
VCC = +15 V, VEE = –15 V, RL = 2.0 kΩ,
TA = Tlow to Thigh
Output Short Circuit Current (VID = 1.0 V, VO = 0 V,
TA = 25°C)
Source
Sink
Common Mode Rejection
RS
≤
10 kΩ, VCM = VICR, TA = 25°C
Power Supply Rejection (RS = 100
Ω)
VCC/VEE = +16.5 V/–16.5 V to +13.5 V/–13.5 V,
TA = 25°C
Power Supply Current (Per Amplifier, No Load)
VCC = +5.0 V, VEE = 0 V, VO = +2.5 V, TA = +25°C
VCC = +15 V, VEE = –15 V, VO = 0 V, TA = +25°C
VCC = +15 V, VEE = –15 V, VO = 0 V,
TA = Tlow to Thigh
NOTES:
3. Tlow = –40°C for MC33071, 2, 4, /A
= 0°C for MC34071, 2, 4, /A
Non–Suffix
Max
3.0
3.0
5.0
—
Min
—
—
—
—
Typ
1.0
1.5
—
10
Max
5.0
5.0
7.0
—
µV/°C
Unit
mV
Symbol
VIO
Min
—
—
—
—
Typ
0.5
0.5
—
10
∆V
IO/∆T
IIB
—
—
IIO
—
—
VICR
VEE to (VCC –1.8)
VEE to (VCC –2.2)
AVOL
50
25
VOH
3.7
13.6
13.4
VOL
4.0
14
—
0.1
–14.7
—
—
—
—
0.3
–14.3
–13.5
3.7
13.6
13.4
—
—
—
4.0
14
—
0.1
–14.7
—
—
—
—
0.3
–14.3
–13.5
100
—
—
—
25
20
100
—
—
—
VEE to (VCC –1.8)
VEE to (VCC –2.2)
6.0
—
50
300
—
—
6.0
—
75
300
100
—
500
700
—
—
100
—
500
700
nA
nA
V
V/mV
V
—
—
—
V
ISC
10
20
CMR
PSR
80
80
30
30
97
97
—
—
—
—
10
20
70
70
30
30
97
97
—
—
—
—
mA
dB
dB
ID
—
—
—
1.6
1.9
—
2.0
2.5
2.8
—
—
—
1.6
1.9
—
2.0
2.5
2.8
mA
Thigh = +85°C for MC33071, 2, 4, /A
= +70°C for MC34071, 2, 4, /A
2–274
MOTOROLA ANALOG IC DEVICE DATA
MC34071,2,4,A MC33071,2,4,A
AC ELECTRICAL CHARACTERISTICS
(VCC = +15 V, VEE = –15 V, RL = connected to ground. TA = +25°C, unless otherwise noted.)
A Suffix
Characteristics
Slew Rate (Vin = –10 V to +10 V, RL = 2.0 kΩ, CL = 500 pF)
AV = +1.0
AV = –1.0
Setting Time (10 V Step, AV = –1.0)
To 0.1% (+1/2 LSB of 9–Bits)
To 0.01% (+1/2 LSB of 12–Bits)
Gain Bandwidth Product (f = 100 kHz)
Power Bandwidth
AV = +1.0, RL = 2.0 kΩ, VO = 20 Vpp, THD = 5.0%
Phase margin
RL = 2.0 kΩ
RL = 2.0 kΩ, CL = 300 pF
Gain Margin
RL = 2.0 kΩ
RL = 2.0 kΩ, CL = 300 pF
Equivalent Input Noise Voltage
RS = 100
Ω,
f = 1.0 kHz
Equivalent Input Noise Current
f = 1.0 kHz
Differential Input Resistance
VCM = 0 V
Differential Input Capacitance
VCM = 0 V
Total Harmonic Distortion
AV = +10, RL = 2.0 kΩ, 2.0 Vpp
≤
VO
≤
20 Vpp, f = 10 kHz
Channel Separation (f = 10 kHz)
Open Loop Output Impedance (f = 1.0 MHz)
Symbol
SR
8.0
—
ts
—
—
GBW
BW
fm
—
—
Am
—
—
en
in
Rin
Cin
THD
—
|ZO|
—
—
—
—
—
—
—
12
4.0
32
0.22
150
2.5
0.02
120
30
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
12
4.0
32
0.22
150
2.5
0.02
120
30
—
—
—
—
—
—
—
—
—
nV/
√
Hz
pA/
√
Hz
MΩ
pF
%
dB
W
60
40
—
—
—
—
60
40
—
—
dB
3.5
—
1.1
2.2
4.5
160
—
—
—
—
—
—
3.5
—
1.1
2.2
4.5
160
—
—
—
—
MHz
kHz
Deg
10
13
—
—
8.0
—
10
13
—
—
µs
Min
Typ
Max
Min
Non–Suffix
Typ
Max
Unit
V/µs
Figure 1. Power Supply Configurations
Figure 2. Offset Null Circuit
VCC
7
–
+
4
2
10 k
3
5
6
1
Single Supply
3.0 V to 44 V
VCC
1
2
3
4
VEE
VEE
VCC
Split Supplies
VCC+|VEE|≤44 V
2
VCC
3
1
VEE
Offset nulling range is approximately
±
80 mV with a 10 k
potentiometer (MC33071, MC34071 only).
VEE
4
MOTOROLA ANALOG IC DEVICE DATA
2–275
MC34071,2,4,A MC33071,2,4,A
Figure 3. Maximum Power Dissipation versus
Temperature for Package Types
P D , MAXIMUM POWER DISSIPATION (mW)
2400
2000
1600
SO–14 Pkg
1200
800
400
0
–55 –40 –20
SO–8 Pkg
8 & 14 Pin Plastic Pkg
V
V IO , INPUT OFFSET VOLTAGE (mV)
4.0
2.0
0
–2.0
–4.0
–55
–25
0
25
50
75
100
125
VCC = +15 V
VEE = –15 V
VCM = 0
Figure 4. Input Offset Voltage versus
Temperature for Representative Units
0
20
40
60
80
100 120 140 160
TA, AMBIENT TEMPERATURE (°C)
TA, AMBIENT TEMPERATURE (°C)
V ICR , INPUT COMMON MODE VOLTAGE RANGE (V)
Figure 5. Input Common Mode Voltage
Range versus Temperature
VCC
VCC
VCC –0.8
VCC –1.6
VCC –2.4
VEE +0.01
VEE
VEE
–55
–25
0
25
50
75
100
125
VCC/VEE = +1.5 V/ –1.5 V to +22 V/ –22 V
Figure 6. Normalized Input Bias Current
versus Temperature
I IB, INPUT BIAS CURRENT (NORMALIZED)
1.3
1.2
1.1
1.0
0.9
0.8
0.7
–55
VCC = +15 V
VEE = –15 V
VCM = 0
–25
0
25
50
75
100
125
TA, AMBIENT TEMPERATURE (°C)
TA, AMBIENT TEMPERATURE (°C)
Figure 7. Normalized Input Bias Current versus
Input Common Mode Voltage
I IB, INPUT BIAS CURRENT (NORMALIZED)
1.4
VO, OUTPUT VOLTAGE SWING (Vpp )
VCC = +15 V
VEE = –15 V
TA = 25°C
50
40
30
Figure 8. Split Supply Output Voltage
Swing versus Supply Voltage
RL Connected
to Ground TA = 25°C
1.2
1.0
RL = 10 k
20
10
0
RL = 2.0 k
0.8
0.6
–12
–8.0
–4.0
0
4.0
8.0
12
0
5.0
10
15
20
25
VIC, INPUT COMMON MODE VOLTAGE (V)
VCC, |VEE|, SUPPLY VOLTAGE (V)
2–276
MOTOROLA ANALOG IC DEVICE DATA
