STANDARD POWER INDUCTORS - SURFACE MOUNT
SMP3013
SMP3013LF
*
PART
NUMBER
SMP3013-101K
SMP3013-121K
SMP3013-151K
SMP3013-181K
SMP3013-221K
SMP3013-271K
SMP3013-331K
SMP3013-391K
SMP3013-471K
SMP3013-561K
SMP3013-681K
SMP3013-821K
SMP3013-102K
SMP3013-122K
SMP3013-152K
SMP3013-182K
SMP3013-222K
SMP3013-272K
SMP3013-332K
SMP3013-392K
SMP3013-472K
SMP3013-562K
SMP3013-682K
SMP3013-822K
SMP3013-103K
SMP3013-123K
SMP3013-153K
SMP3013-183K
SMP3013-223K
SMP3013-273K
SMP3013-333K
SMP3013-393K
SMP3013-473K
SMP3013-563K
SMP3013-683K
SMP3013-823K
SMP3013-104K
TRADITIONAL
Pb
COMPLIANT
RoHS
Wirewound, Molded
L µH
@1 kHz
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
DCR
OHMS
MAX
FERRITE CORE
0.030
0.046
0.056
0.061
0.083
0.096
0.109
0.120
0.131
0.194
0.198
0.221
0.258
0.278
0.314
0.346
0.480
0.535
0.715
0.970
1.06
1.18
1.57
1.76
1.92
2.16
3.12
3.38
4.66
6.36
7.20
7.92
8.90
12.1
13.7
18.2
20.9
SATURATION CURRENT
A DC
4.6
4.2
3.6
3.4
3.0
2.6
2.4
2.2
2.0
1.8
1.6
1.5
1.4
1.2
1.1
1.0
0.980
0.860
0.780
0.680
0.660
0.580
0.520
0.470
0.450
0.400
0.360
0.330
0.290
0.270
0.235
0.210
0.200
0.185
0.170
0.150
0.130
CURRENT RATING
A DC
2.78
2.69
2.03
1.95
1.69
1.55
1.46
1.39
1.33
1.10
1.08
1.02
0.946
0.912
0.858
0.817
0.694
0.657
0.568
0.488
0.467
0.442
0.384
0.362
0.347
0.327
0.272
0.261
0.223
0.191
0.179
0.171
0.161
0.138
0.130
0.113
0.105
Suffix “K” for 10% tolerance
Custom designs are available to meet your specific requirements; please contact factory.
*Add “LF” suffix for RoHS requirement. Example: SMP3013-101KLF
Gowanda designates a component RoHS-compliant by adding “LF” (lead free) to the part number.
These LF components meet the ≤ .1% lead requirement and they are compatible with 260°C soldering processes.
MARKING: PXXXK
0.300/0.325
(7.62/8.26)
OVER TERMINAL
0.125/0.145
(3.18/3.68)
OVER TERMINAL
RECOMMENDED FOOT PRINT
0.075 (1.91)
0.100
(2.54)
0.310
(7.87)
CENTERS
NOTES:
• Operating Temperature Range:
-55°C to +125°C
• Current Rating is based on a 40°C temperature
rise at an ambient temperature of 85°C
• Saturation Current is the approximate value
that will reduce the initial inductance by 5%
TAPE AND REEL SPECS:
Pcs./Reel maximum:
Pitch between parts:
Tape width:
Reel diameter:
2200
8 mm
16 mm
13 in.
0.070
(1.78) REF
0.110/0.130
(2.79/3.30)
0.040/0.060 (1.02/1.52) WIDE X
0.020 (0.508) MIN DEEP
2 SIDES
in. (mm)
One Magnetics Pkwy, Gowanda, NY 14070 • (t) 716-532-2234 • (f) 716-532-2702 • sales@gowanda.com
www.gowanda.com
122813
