BTCPower
4BESeries
Features
•
•
•
•
•
•
•
TM
Broadband TelCom Power,
Inc.
Redefining “Current” Limits In Power Conversion
10W DC-DC Converters
10W Isolated Output
2:1 Input Range
82% Efficiency
Pi Input Filter
Low Ripple and Noise
Continuous Short Circuit Protection
Conductive EMI Meet EN55022 Class A
Model
Number
4BE-01
4BE-02
4BE-03
4BE-04
4BE-05
4BE-06
4BE-11
4BE-12
4BE-13
4BE-14
4BE-15
4BE-16
4BE-21
4BE-22
4BE-23
4BE-24
4BE-25
4BE-26
Input
Voltage
Output
Voltage
5 VDC
12 VDC
15 VDC
±12 VDC
±15 VDC
±5 VDC
5 VDC
12 VDC
15 VDC
±12 VDC
±15 VDC
±5 VDC
5 VDC
12 VDC
Output Current
Min.
Max.
100 mA
45 mA
35 mA
±25 mA
±20 mA
±50 mA
100 mA
45 mA
35 mA
±25 mA
±20 mA
±50 mA
100 mA
45 mA
35 mA
±25 mA
±20 mA
±50 mA
2000 mA
830 mA
666 mA
±415 mA
±333 mA
±1000 mA
2000 mA
830 mA
666 mA
±415 mA
±333 mA
±1000 mA
2000 mA
830 mA
666 mA
±415 mA
±333 mA
±1000 mA
Input Current
No Load
Full Load
30
30
30
40
40
40
20
20
20
20
20
20
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
mA
1100 mA
1065 mA
1065 mA
1065 mA
1065 mA
1065 mA
535 mA
520 mA
520 mA
520 mA
520 mA
520 mA
260 mA
254 mA
254 mA
254 mA
254 mA
254 mA
% Efficiency
Case
9-18DC
76
78
78
78
78
78
78
80
80
80
80
80
80
82
82
82
82
82
B
18-36 VDC
B
10 mA
10 mA
36-72 VDC
15 VDC
±12 VDC
±15 VDC
±5 VDC
10 mA
10 mA
10 mA
10 mA
B
Note: Nominal Input Voltage 12, 24, 28 or 48VDC
Broadband TelCom Power, Inc. –
1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A.
Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com
DS LP 4BE Rev2 16-1-04
4BE Series
Specifications
Input Specifications:
10W DC-DC Converters
BTCPower
TM
Input Voltage Range…………………….12V…………..………..9-18V
24V……………..……18-36V
48V…………………..36-72V
Input Filter………………………………………………………..Pi Type
Output Specifications:
Voltage Accuracy……………Single output…...……….+/- 1.0 % max.
Dual (+/-) output… ….+/- 1.0 % max.
Voltage Balance ( Dual )………………………………...+/- 1.0 % max.
Transient Response
Single 25% Step Load Change…………………………….<500ìsec.
Dual FL. 1/2L+/-1% Error Band…………………………….<500ìsec
Ripple & Noise, 20 MHz BW………………………. 100 mV p-p max.
Temperature Coeffcient………………………… +/- 0.02 % / ºC max.
Short Circuit Protection………………………………..……Continuous
Line Regulation ¹ Single / Dual Output………….……..+/- 0.2 % max.
Load Regulation ² Single / Dual Output……………...….+/- 1 % max.
General Specifications
:
Efficiency………………………………………………..……...see table
Isolation Voltage….…………………………………………500VDCmin
Isolation Resistance………………………………………….100Mohm
Switching Frequency……………………………………..200 KHz, min.
Operating Temperature Range…………………………-25ºC ~ +71ºC
Case Temperature………………………………………….100 ºC max.
Cooling……………………………………………….Free air convection
Storage Temperature Range……………………..…..-40 ºC ~ +100ºC
EMI / RFI…………………………………………………..Six sied shield
Dimensions………………..……2” x 1” x 0.4“ (50.8 x 25.4 x 10.2 mm)
Case Material………………………………..Black Coated Copper with
Non-conducted base
Note:
1. Measured from high line to low line;
2. Measured from full load to ¼ load;
3. Minimum load on the output is necessary to maintain regulation
Outline Information and Pin-out
PIN CONNECTION
Pin
1
2
3
4
5
Function
+ Input
- Input
+ Output
Common / NP
- Output
* NP---No Pin On Single Output
All dimensions are in inches [mm]
The information and specifications contained in this brief are believed to be accurate and reliable at the time of publication. Specifications are
subject to change without notice. Refer to product specification sheet for performance characteristics and application guidelines.
Broadband TelCom Power, Inc. –
1719 S. Grand Avenue, Santa Ana, CA 92705 U.S.A.
Tel.: 714-259-4888 • Fax: 714-259-0840• www.btcpower.com • Email: sales@btcpower.com
DS LP 4BE Rev2 16-1-04
