BOT123Series
3 Way 2 Tier 3mm LED
Array
The BOT123 series is a family of devices
using Black NYLON 6 VO rated housing to
mount 3mm LEDs at right angles to the
PCB forming an 3x2 LED Array.
•
+/- 25 Deg Viewing Angle
•
•
•
•
Good matching
Direct equivalent to Marl 123 series.
End stackable.
Wide range of LED types available
MECHANICAL DATA
15.24
4.0
10.0
This
component
is RoHS
compliant
Pb
1
2
3
4
5
10.16
5.08
6
2.54
+
5.08
+
5.08
3.4
+
2.54
6.84
0.5 SQ
BEDFORD OPTO TECHNOLOGY LTD
1,BIGGAR BUSINESS PARK, BIGGAR,LANARKSHIRE ML12 6FX
Tel: +44 (0) 1899 221221 Fax: +44 (0) 1899 221009
Website: bot.co.uk E-mail: bill@bot.co.uk
PAGE 1 OF 2
10.3.06 ISS C
ABSOLUTE MAXIMUM RATINGS
(T
A
= 25
O
C)
REVERSE VOLTAGE
CONTINUOUS FORWARD CURRENT
POWER DISSIPATION
OPERATING TEMP
STORAGE TEMP
LEAD SOLDERING TEMP(2mm FROM BODY 5secs)
6 Volts
30 mA
100 mW
-40 TO+100
O
C
-55to +100
O
C
260
O
C
BOT123 Series
This
component
is RoHS
compliant
Pb
OPTO ELECTRONIC DATA
(Ta = 25
O
C)
COLOUR
Lumenous Intensity
If = 10mA
mcd
Peak Wavelength
nm
-
635
-
-
585
-
565
-
Forward Voltage
If = 20mA
volts
-
2.0
3.0
-
2.4
-
2.4
3.0
VIEWING ANGLE
deg
HE RED
min
typ
max
min
typ
min
typ
max
6.3
-
30
YELLOW
6.3
30
GREEN
6.3
-
30
PURE
GREEN
Min
Typ
max
1.6
555
2.4
3.0
30
SOFT
ORANGE
Min
Typ
max
1.6
605
2.4
3.0
30
ORDERING INFORMATION
POSITION
1
X
2
X
3
X
4
X
5
X
6
X
BOT123
X=R=RED,G=GREEN,Y=YELLOW,PG=PURE GREEN,O=SOFT ORANGE
BEDFORD OPTO TECHNOLOGY LTD
1,BIGGAR BUSINESS PARK, BIGGAR,LANARKSHIRE ML12 6FX
Tel: +44 (0) 1899 221221 Fax: +44 (0) 1899 221009
Website: bot.co.uk E-mail: bill@bot.co.uk
10.3.06 ISS C
PAGE 2 OF 2
