S/MOD/SKD10306/A/29/11/1999
page 1 / 2 F/GB
RELAIS STATIQUE DC POUR CIRCUIT IMPRIME
DC SOLID STATE RELAY FOR PRINTED CIRCUIT BOARD
• Gamme pour circuit imprimé.
• Sortie DC .
•
Range for printed circuit board
•
DC Output.
SKD10306
3-30 VDC input
3 A / 60 VDC output
Aplication typique/Typical application
+
43,2
±0, 4
10,2
±0,35
1+
+3
±0,35
25,4
1+
-4
2-
2-
Charge
/
Load
4 -3 +
2-
1+
6,5
±0, 5
Ø1
7,62
(*)
7,63
5,08
±0, 2
±0,2
12,7
10,16
±0, 2
TOLERANCES: ±0,3
(*)
Sur charges inductives./
On inductive loads
-
Caractéristiques d'entrée (à 20°C)
/ Input characteristics (20
°
C)
Paramètre /
Parameter
Plage de tension de commande (Uc) /
Input voltage range (Uc)
Tension maximum de commande /
Maximum control voltage
Tension minimum de commande /
Minimum control voltage
Courant de fonctionnement/Operating
current
Courant maximum de commande /
Maximum control current
Tension de relachement/Release
voltage
Résistance interne /
Input internal resistor
Symbol
Uc
Uc max
Uc min
Ic
Ic max
Uc off
Rc
3-30
30
3
1
30
1
1000
Unit
VDC
VDC
VDC
mADC
mADC
VDC
Ω
Caractéristiques générales /
General characteristics
Paramètre /
Parameter
Température de stockage /
Storage temperature
Température de fonctionnement /Operating
temperature
Tension d'isolement entrée-sortie /
Input-output isolation voltage
Capacité entrée-sortie/
Input-output capacity
Poids/Weight
- 40 à/to +105
-40 à/to +80
2500
8
20
Unit
°C
°C
VRMS
pF
g
Proud to serve you
All
technical characteristics are subject to change without previous
Caractéristiques sujettes à modifications sans préavis.
notice.
celduc
r
e
l
a
i
s
S/MOD/SKD10306/A/29/11/1999
page 2 / 2 F/GB
Caractéristiques de sortie (à 20°) /
Output characteristics(20
°
C)
Paramètre /
Parameter
Tension nominale /
Nominal voltage
Plage tension de fonctionnement /
Operating range
Tension crête /
Peak voltage
Courant nominal (voir les caractéristiques thermiques)
/
Nominal current (see thermal curves)
Courant de surcharge accidentel admissible maximum
/
Maximum accidental overload current
Chute tension directe (In) /
On state voltage drop (IN)
Courant de fuite état bloqué
/
Off state leakage current
Courant de charge minimum /
Minimum load current
Temps de fermeture /
Turn on time
Temps d'ouverture /
Turn off time
Fréquence d'utilisation /
Operating frequency
dv/dt état bloqué /
Off state dv/dt
Homologation /
Approval
-
2 à/to 60
60
3
10
1,6
1
5
200
800
0 à/to 500
200
Nous consulter /Consult
us
Unit
VDC
VDC
VPEAK
A
APEAK
VDC
mA
mA
µs
µs
Hz
V/µs
Fig.2 Caractéristiques thermiques /
thermal curves :
5
4
Courant commuté (A)
/
Switched current (A)
Tension de commande/
Input voltage
<10VDC sans/
without
LED
3
2
1
0
0
10
20
30
40
50
60
70
80
90
100 110
Température ambiante (°C) / Ambient temperature (°C)
Tension de commande/
Input voltage
=30VDC ou
modèles avec LED/or
models with LED
Précautions :
* Les relais à semiconducteurs ne procurent pas d'isolation
galvanique entre le réseau et la charge.
* Dans le cas de plusieurs modules côte à côte, prévoir un dé-
rating en courant.
* Sur charges inductives prévoir une diode de roue libre (ou
écrêteur de surtension ).
Cautions
:
* Semiconductor relays don't provide any galvanic insulation
between the load and the mains.
* In case of many SSRs side by side, take a derating current
in to account.
*
On inductive loads put a free-wheeling diode (or clamp ).
celduc
r
e
l
a
i
s
www.celduc.com
Rue Ampère B.P. 4
42290 SORBIERS - FRANCE
E-Mail : celduc-relais@celduc.com
Fax +33 (0) 4 77 53 85 51
Service Commercial France Tél. : +33 (0) 4 77 53 90 20
Sales Dept.For Europe Tel. : +33 (0) 4 77 53 90 21 Sales Dept. Asia : Tél. +33 (0) 4 77 53 90 19
