MIL-DTL-5015 Style Circular Connectors
D/MS A/B Series
◆
OUTLINE
D/MS A/B series is compatible with MIL-DTL-5015 and
Conforming
Standard
MIL-DTL-5015
RoHS2
a soldering termination connector.
A various combination of the plugs, receptacles and
accessories is also available and can be used for cable-
to -cable usage and cable-to-panel usage.
D/MS A/B series is provided with 12 kinds of shell sizes
from 10SL to 36, 5 kinds of contact size from #16 to #0
and 73 kinds of insert arrangements to accommodate a
wide variety of applications.
◆
APPLICATIONS
Aerospace, Machine Tool, Measurement Equipment, Communication Equipment and Other Industrial Equipment
MIL-DTL-5015 Class A and B
UL, C-UL Approved: File Number E72124
Lock Type
Threaded
Coupling
◆
SAFETY STANDARD
◆
CONFORMING STANDARD
◆
FEATURES
●The barriers are placed between each contact on the insert to extend the creepage
distance for the improvement of dielectric withstanding voltage characteristic.
●Each of the plug shells and the receptacle shells can apply to both of the pin insert
assemblies and the socket insert assemblies respectively excluding shell size 10SL.
●A combination of the sockets for input and pin for output is recommended since
D/MS A/B series is often used for high voltage equipment to prevent from any accidents.
Barrier
●The plug shell has a key way and the receptacle shell has a key. The key will be inserted into the
key way before the contacts are mated. The insert is rotated within the shell from standard key way
and 4 kinds of alternate insert positions, W, X, Y and Z are available to avoid cross–plugging
problem in applications requiring the use of more than one connector of the same size and
arrangement.
●The solder cups in the insert assembly face in same direction to solder cables easier.
●The surface of shells is coated with zinc plating and finished with trivalent chromium treatment(*) in
color black to conform to RoHS directives. (* : Cadmium plating and Olive Drab color is MIL- DTL-
5015 specification). The conventional DMS series in Olive Drab color is also available upon your
request.
DDK
190329
Other Manufacture's
◎ Specifications and/or dimensions in this catalog are subject to change without notice.
Your checking the latest specifications with our drawings would be highly appreciated.
http://www.ddknet.co.jp
D/MS A/B Series
○ SPECIFICATIONS
Rated Current
Contact Size
＃ 16
＃ 12
＃8
＃4
＃0
Assembled in Insulator
13A max.
23A max.
46A max.
80A max.
150A max.
DC
250V
700V
1,250V
1,750V
AC(r.m.s.)
200V
500V
900V
1,250V
Rated Voltage
Service Rating
INST
A
D
E
Dielectric
Withstanding
Voltage
Service Rating
INST
A
D
E
Dielectric Withstanding Voltage at 1minute
1,000V AC(r.m.s.)
2,000V AC(r.m.s.)
2,800V AC(r.m.s.)
3,500V AC(r.m.s.)
Insulation
Resistance
Contact
Resistance
5000MΩ min. at 500V DC
Contact Size
＃ 16
＃ 12
＃8
＃4
＃0
Test Current Voltage Descent
13A
23A
46A
80A
150A
87mV max.
77mV max.
80mV max.
70mV max.
65mV max.
Operating
Temperature
Applicable
Cable Size
-55℃ 〜 +125℃
Contact Size
＃ 16
＃ 12
＃8
＃4
＃0
Applicable Cable Size
A.W.G.
#16 〜＃ 22
#12 〜 #14
#8 〜 #10
#4 〜 #6
#0 〜 #2
Official Sectional Area Conductor Diameter
1.25mm
2
3.50mm
2
2
2
2
1.6mm Max.
2.5mm Max.
4.5mm Max.
7.0mm Max.
11.0mm Max.
8.00mm
22.00mm
50.00mm
○ MATERIAL / FINISH
Item
Contact
Insert
Shell
Retaining Ring
Gasket
Material / Finish
Copper Alloy / Silver or Gold Plating
Diallyl Phthalate Resin(Blue)
Aluminum Alloy / Zinc Plating, Black Trivalent Chromium Treatment
Copper Alloy / Nickel Plating
Synthetic Rubber (Nitrile)
Compliant
Compliant
RoHS
◎ Specifications and/or dimensions in this catalog are subject to change without notice.
Your checking the latest specifications with our drawings would be highly appreciated.
http://www.ddknet.co.jp
2
D/MS A/B Series
○ D/MS Series A/B Type Ordering Information
D/MS3 10 2 A1 8- 1 0P Y
(6 2 )
Connector Style
D/MS3100A
Wall Mount Receptacle
Deviation
Omit : Silver Plated Contacts (Standard)
(62) : Gold Plated Contacts (0.5 μ m AU over Ni)
Alternate Insert Position
No letter is required for normal
position. The alternate insert
positions, W, X, Y and Z, are
available. W, X, Y and Z designate
that an insert is rotated in its shell
from the standard position. For
detailed alternate insert positions,
refer to page 8
C
Ｌ
（12S 〜 36 Size)
D/MS3101A
Cable Receptacle
Ｗ
Ｘ
Ｚ
Ｙ
（12S 〜 36
Size）
D/MS3102A
Box Mount Receptacle
Contact Type
Ｐ ：Pin Contact
S ： Socket Contact
When a receptacle connector has
pin contacts (P), its mating plug
connector should have socket
contacts(S). Reverse style of
contacts is also feasible.
（10SL 〜 36 Size）
D/MS3106A
Straight Plug
Shell Size
Shell sizes are designated by the
screw size of mating part which is
described in inches multiply by 16.
(e.g.) When the screw size of mating
part is 1 1/8-18, it is 1 1/8 X 16 =18
of which shell size is 18.
(Available shell size) :
10SL,12S,14S,16S, 16, 18, 20, 22,
24, 28, 32 and 36.
Insert Arrangement
This is the number allocated to each shell size
respectively with its sequential number beginning from
number one(1). (However, there are the numbers
which are not used.) The insert arrangement number
does not show the number of contacts.
For example on the insert arrangement 18-10:
18 shows the shell size. 10 shows the insert
arrangement. (The number of contacts is 4.)
With regard to the insert arrangement, refer to page
4 to page 7.
（10SL 〜 36 Size）
D/MS3106B
Straight Plug
(Split Backshell)
（12S 〜 36 Size）
D/MS3108B
Right Angle Plug
(Split Backshell)
（12S 〜 36 Size）
◎ Specifications and/or dimensions in this catalog are subject to change without notice.
Your checking the latest specifications with our drawings would be highly appreciated.
http://www.ddknet.co.jp
3
D/MS A/B Series
○ Insert Arrangement List
