PMS 300 neg.
Black neg.
AC(X)
resistors
AC terminator networks
EU
features
•
•
•
•
•
Thin film construction
Surface mount package
Stable resistor technology
High component density
Products with lead-free terminations meet EU RoHS
and China RoHS requirements
applications
•
Signal termination
•
Signal conditioning
•
DC current blocking
dimensions and construction
Bonding
Wire
L
W
a
p
w
Lead
Die
Pad
Si
Wafer
Molded
Resin
H
Q20
Q24
1 watt
1 watt
20
24
Package Total
Code Power
Dimensions
inches
(mm)
L ±0.2 W ±0.2 w ±0.2 H ±0.2 p ±0.1
.341
(8.66)
.341
(8.66)
.236
(5.99)
.236
(5.99)
150
(3.81)
150
(3.81)
.063
(1.60)
.063
(1.60)
.025
(0.635)
.025
(0.635)
c
Pins
a ±0.1
.010
(0.25)
.010
(0.25)
c ±0.1
.026
(0.66)
.026
(0.66)
circuit schematic
Single Common
4 Commons
6 Commons
ACB:
20 pins
ACC:
20 pins
ACD:
24 pins
ordering information
New Part #
ACB
Type
ACB
ACC
ACD
Q20
Package
Code
Reference
above table
T
Termination
Material
T: Sn
(Other termination
styles available,
contact factory
for options)
TEB
Packaging
TEB: 13"
embossed
plastic tape
500
Nominal
Resistance
2 significant
digits +
number
of zeros
K
Tolerance
K: ±10%
/
101
Nominal
Capacitance
2 significant
digits +
number
of zeros
M
Tolerance
M: ±20%
For further information on packaging, please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
11/21/08
140
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
AC(X)
Parallel Termination
V
Term
50 ohms
AC terminator networks
Driver
100 pF
Receiver
applications and ratings
Part
Designation
ACB
ACC
ACD
Power Rating
@ 70°C
(Per Element)
100mW
T.C.R.
(ppm/°C)
Capacitor
Voltage
Rating
20V
Operating
Temperature
Range
-55°C to
+125°C
Resistance
Range
Ω
(E-24)
10 ~ 1,000
Resistance
Tolerance
Capacitor
Range
pF (E-24)
33 ~ 400pF
Capacitor
Tolerance
±200
K: ±10%
M: ±20%
environmental applications
Performance Characteristics
Parameter
Resistance to Soldering Heat
Short Time Overload
Moisture Resistance
Thermal Shock
H.A.S.T.
Maximum
∆
R
+0.25%
+0.50%
+0.50%
+0.50%
+1%
MIL-R-55342 4.7.7
MIL-R-55342 4.7.5
MIL-STD-202 method 103
MIL-STD-202 method 107
2 Atm., 121°C, 96 hrs
Test Method
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
11/29/04
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
141
