EDBS03TTE5V0: Descriptionbidirectional esd suppressor; CategoryDiscrete semiconductor diode; File Size90KB，2 Pages; ManufacturerKOA Speer; Websitehttp://www.koaspeer.com/; Environmental Compliance

Download Datasheet Parametric Compare View All

EDBS03TTE5V0 Overview

bidirectional esd suppressor

EDBS03TTE5V0 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Maker	KOA Speer
package instruction	R-PDSO-G3
Contacts	3
Reach Compliance Code	compli
ECCN code	EAR99
Maximum breakdown voltage	27 V
Minimum breakdown voltage	16 V
Configuration	COMPLEX
Diode component materials	SILICON
Diode type	TRANS VOLTAGE SUPPRESSOR DIODE
JESD-30 code	R-PDSO-G3
JESD-609 code	e3
Humidity sensitivity level	1
Number of components	4
Number of terminals	3
Package body material	PLASTIC/EPOXY
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
polarity	BIDIRECTIONAL
Maximum power dissipation	0.225 W
Certification status	Not Qualified
surface mount	YES
technology	AVALANCHE
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrie
Terminal form	GULL WING
Terminal location	DUAL
Maximum time at peak reflow temperature	3

Preview

Download Datasheet

View All

PMS 300 neg.

Black neg.

ED(X)

EU

features

•

(16kV) IEC 61000-4-2 rating

Surface mount package

High component density

Products with lead-free terminations meet EU RoHS

and China RoHS requirements

bidirectional esd suppressor

circuit

protection

applications

•

ESD suppression

•

Transient suppression

dimensions and construction

S03

S05

L

P

Bonding

Wire

Die

Pad

W

Molded

Resin

Si

Wafer

Lead

d

Molded

Resin

W

P

d

L

p

Bonding

Wire

Die

Pad

Lead

Si

Wafer

Package Total

Code Power

S03

225mw

Pins

3

5

6

Dimensions

inches

(mm)

L ±0.2 W ±0.2 p ±0.1 P ±0.1

Pkg Ht

±0.2

.114

(2.90)

.114

(2.90)

.114

(2.90)

.091

(2.30)

.110

(2.80)

.110

(2.80)

––

.037

(0.95)

.037

(0.95)

.075

(1.90)

.075

(1.90)

––

.039

(1.0)

.039

(1.0)

.039

(1.0)

d ±0.05

.017

(0.43)

.017

(0.43)

.017

(0.43)

S06

L

p

Bonding

Wire

Lead

W

Si

Wafer

Molded

Resin

d

Die

Pad

S05

S06

circuit schematic

EDA

EDB

EDC

EDD

3

2

1

4

5

6

3

2

1

4

5

6

3

2

1

4

3

2

5

1

ordering information

New Part #

EDA

Type

EDA

EDC

EDB

EDD

S03

Package

Code

From table above

T

Lead

Plating

T: Sn

TE

Packaging

TE: 7" embossed

plastic tape

16V

Voltage

5V0

16V

For further information on packaging, please refer to Appendix A.

Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.

2/24/08

196

KOA Speer Electronics, Inc.

• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
