CTX
resistors
PECL clock terminator networks
EU
features
•
•
•
•
•
EMI/RFI attenuation
Reduced board space
Better tracking of electrical parameters
Precision characteristics
Products with lead-free terminations meet EU RoHS
and China RoHS requirements
applications
•
Low pass filter
•
Clock termination
•
EMI/RFI attenuator
dimensions and construction
A
L
d
h
circuit schematic
2
C
R1
c
p
W
R2
1
Dimensions
inches
(mm)
p
h
A
3
Size
Code
S03
L
W
d
c
.115±.001 .091±.001 .045±.001 .075±.004 .037±.004 .017±.004 .016±.004
(2.92±0.2) (2.30±0.2) (1.15±0.2) (1.91±0.1) (0.95±0.1) (0.43±0.1) (0.40±0.1)
ordering information
New Part #
CTX
Type
S03
Package
Symbol
Package type symbol
+ number of pins
SOT23: S03
T
Termination Material
T: Sn
(Other termination
styles available,
contact factory
for options)
TE
Packaging
TE: 7"
embossed
plastic tape
XXXX*
Custom Value
Code
* Value code assigned by
KSE Engineering
applications and ratings
Part
Designation
Power Rating
@ 70°C
(Resistor)
100mW
Capacitor
Voltage
Rating
20V
Resistor
Tolerance
T.C.R.
(ppm/°C)
Capacitor
Tolerance
Operating
Temperature
Range
-55°C to +150°C
CTX
±10%
±200
±20%
For further information on packaging, please refer to Appendix A.
Specifications given herein may be changed at any time without prior notice. Please confirm technical specifications before you order and/or use.
2/12/08
144
KOA Speer Electronics, Inc.
• 199 Bolivar Drive • Bradford, PA 16701 • USA • 814-362-5536 • Fax: 814-362-8883 • www.koaspeer.com
