1
Description:
ON-VEHICLE LOW PROFILE ANTENNA
Series: Shadow
PART NUMBER: Black: SLPTXXX / White: SLPTXXXW
This document covers all product variants of the following product family:
Project
Color
Frequency
Size
Fixing System
Connector
SLPT698/2170NMOHFW
White
698-960MHz
1710-2700MHz
SLPT698/2170NMOHF
Black
NMOHF
NMO + HF Connector
SLPT698/960NMOW
SLPT698/960NMO
White
698-960MHz
Black
SLPT806NMOW
SLPT806NMO
SLPT698/869DMNW
SLPT698/869DMN
SLPT806DMNW
SLPT806DMN
SLPT698/2170DMNW
SLPT698/2170DMN
White
Black
White
806-960MHz
NMO + Pogo Pin Connector
698-869MHz
Black
White
806-960MHz
Black
White
Black
698-960MHz
1710-2700MHz
Direct Mount
N Female Connector
(Screw 5/8-24 UNEF 2A)
2
Issue: 1640
In the effort to improve our products, we reserve the right to make changes judged to be necessary.
CONFIDENTIAL AND PROPRIETARY INFORMATION
This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws.
Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or
use without specific written authorization of Pulse is strictly forbidden.
Description:
ON-VEHICLE LOW PROFILE ANTENNA
Series: Shadow
PART NUMBER: Black: SLPTXXX / White: SLPTXXXW
This document covers all product variants of the following product family:
Project
SLPT2400NMOHFW
SLPT2400NMOHF
SLPT4900NMOHFW
SLPT4900NMOHF
SLPT245NMOHFW
SLPT2400/5900NMOHF
SLPT2400DMNW
SLPT2400DMN
SLPT4900DMNW
SLPT4900DMN
SLPT2400/5900DMNW
SLPT2400/5900DMN
Color
White
Black
White
Black
White
Black
White
Black
White
Black
White
Black
Frequency
2400-2500MHz
Size
Fixing System
Connector
4900-6000MHz
2400-2500MHz
4900-6000MHz
2400-2500MHz
NMOHF
NMO + HF Connector
4900-6000MHz
2400-2500MHz
4900-6000MHz
Direct Mount
N Female Connector
(Screw 5/8-24 UNEF 2A)
P.S.: For DMN fixing system, it requires a 5/8” (16mm) hole in the
mounting surface.
Remove any burrs, particularly on the Roof under side of the hole.
Remove paint in a narrow ring around the hole. Metal-to-metal contact
between the mounting surface and mount is essential for best
performance.
3
Issue: 1640
In the effort to improve our products, we reserve the right to make changes judged to be necessary.
CONFIDENTIAL AND PROPRIETARY INFORMATION
This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws.
Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or
use without specific written authorization of Pulse is strictly forbidden.
Description:
ON-VEHICLE LOW PROFILE ANTENNA
Series: Shadow
PART NUMBER: Black: SLPTXXX / White: SLPTXXXW
ELECTRICAL SPECIFICATIONS
Project
SLPT698/2170NMOHFW
Frequency
VSWR
Peak Gain
Efficiency
SLPT698/2170NMOHF
698-960MHz
1710-2700MHz
3:1(0.698-0.716GHz)
2.5:1(0.716-0.772GHz)
2:1(0.772-0.9GHz)
3.52dBi(0.698-0.96GHz)
2.5:1(0.9-0.934GHz)
4.95dBi(1.71-2.69GHz)
3:1(0.934-0.96GHz)
1.7:1(1.71-2.5GHz)
2.2:1(2.5-2.7GHz)
2:1
3.29dBi
72%
71%
SLPT698/960NMOW
698-960MHz
SLPT698/960NMO
SLPT806NMOW
806-960MHz
SLPT806NMO
SLPT698/869DMNW
698-869MHz
SLPT698/869DMN
SLPT806DMNW
806-960MHz
SLPT806DMN
SLPT698/2170DMNW
698-960MHz
1710-2700MHz
1.5:1
2:1
2:1
68%
3.18dBi
67%
3.26dBi
72%
3.05dBi
70%
76%
67%
SLPT698/2170DMN
3:1(0.698-0.732GHz)
2.5:1(0.732-0.774GHz)
2:1(0.774-0.852GHz)
2.5:1(0.852-0.903GHz) 3.51dBi(0.698-0.96GHz)
3:1(0.903-0.96GHz)
4.81dBi(1.71-2.69GHz)
1.7:1(1.71-2.5GHz)
2.2:1(2.5-2.7GHz)
Issue: 1640
4
In the effort to improve our products, we reserve the right to make changes judged to be necessary.
CONFIDENTIAL AND PROPRIETARY INFORMATION
This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws.
Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or
use without specific written authorization of Pulse is strictly forbidden.
Description:
ON-VEHICLE LOW PROFILE ANTENNA
Series: Shadow
PART NUMBER: Black: SLPTXXX / White: SLPTXXXW
ELECTRICAL SPECIFICATIONS
Project
SLPT2400NMOHFW
Frequency
VSWR
Peak Gain
Efficiency
2400-2500MHz
SLPT2400NMOHF
SLPT4900NMOHFW
SLPT4900NMOHF
SLPT245NMOHFW
SLPT2400/5900NMOHF
SLPT2400DMNW
2400-2500MHz
SLPT2400DMN
SLPT4900DMNW
4900-6000MHz
SLPT4900DMN
SLPT2400/5900DMNW
SLPT2400/5900DMN
4900-6000MHz
1.5:1
5.06dBi
79%
2:1
5.09dBi
71%
2400-2500MHz
4900-6000MHz
1.5:1(2.4-2.5GHz)
2:1(4.9-6GHz)
5.06dBi
5.09dBi
79%
71%
1.5:1
4.78dBi
75%
2:1
5.14dBi
73%
2400-2500MHz
4900-6000MHz
1.5:1(2.4-2.5GHz)
2:1(4.9-6GHz)
4.78dBi
5.14dBi
79%
73%
Nominal Impedance
Radiation Pattern
Polarization:
Power with standing
Issue: 1640
50
omni
Vertical
10W
5
In the effort to improve our products, we reserve the right to make changes judged to be necessary.
CONFIDENTIAL AND PROPRIETARY INFORMATION
This document contains confidential and proprietary information of Pulse Electronics, Inc. (Pulse) and is protected by copyright, trade secret and other state and federal laws.
Its receipt or possession does not convey any rights to reproduce, disclose its contents, or to manufacture, use or sell anything it may describe. Reproduction, disclosure or
use without specific written authorization of Pulse is strictly forbidden.
