T-17103: Description10/100BASE-TX QUAD PORT TRANSFORMER; File Size117KB，3 Pages; ManufacturerRhombus Industries, Inc.; Websitehttp://www.rhombus-ind.com/

Download Datasheet Compare View All

T-17103 Overview

10/100BASE-TX QUAD PORT TRANSFORMER

Preview

Download Datasheet

View All

10/100BASE-TX QUAD PORT TRANSFORMER

Meets all IEE 802.3u and ANSI X3.263 stan-

dards including 350

µH

OCL with 8 mA bias

Model designed to support four single or

double stacked RJ-45 connectors

Electrical Specifications at 25

Insertion

Part

Loss

Return Loss

Number (dB TYP.)

(dB MIN )

.1-100MHz

Crosstalk

(dB TYP)

Common to common

Rejection Ratio

0.1-60MHz(dB typ.)

Transmit

Receive

Differential to

Common Mode

Rejection (dB typ.)

1-60MHz 60-200MHz

-40

-30

2-30MHz 40MHz 50MHz 60-80MHz 1MHz 30MHz 60MHz 100MHz

T-17100

T-17101

T-17102

T-17103

T-17104

T-17105

-0.5

-21

-17

-14.5

-12

-65

-55

-50

-55

-50

-45

-40

-45

-40

-35

-30

-35

-30

Dimensions in inches (mm)

Tape and Reel available.

1.120

(28.45)

MAX.

.485

(12.32)

MAX.

.230

(5.84)

MAX.

.016

(0.41)

TYP.

.050

(1.27)

TYP.

.010

(0.25)

TYP.

.045

(1.14)

TYP.

.010

(0.25)

TYP.

.640 (16.26)

.620 (15.75)

100-qp40

Rhombus

Industries Inc.

Transformers & Magnetic Products

www.rhombus-ind.com

15801 Chemical Lane, Huntington Beach, CA 92649

Phone: (714) 898-0960

FAX: (714) 896-0971
