NAT-I-SC-9-1 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Wireless rf/communication> Optical fiber> NAT-I-SC-9-1

NAT-I-SC-9-1: DescriptionFixed Attenuator, SC/SPC Connector, Through Hole Mount,; CategoryWireless rf/communication Optical fiber; File Size174KB，1 Pages; ManufacturerDicon Fiberoptics Inc; Websitehttp://www.diconfiberoptics.com

Download Datasheet Parametric View All

NAT-I-SC-9-1 Overview

Fixed Attenuator, SC/SPC Connector, Through Hole Mount,

NAT-I-SC-9-1 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
body width	25 mm
body height	12 mm
Body length or diameter	50 mm
Connection Type	SC/SPC CONNECTOR
Fiber optic equipment types	FIXED ATTENUATOR
Installation features	THROUGH HOLE MOUNT
surface mount	NO
change control organization	VOLTAGE
Base Number Matches	1

Preview

Download Datasheet

View All

Attenuators

Specifications

Attenuators

Ordering Information

NAT -

Monitor

FC/APC

FC/UPC

SC/APC

SC/UPC

ST/UPC

LC/UPC

MU/UPC

Input

Output

Input and output

None

FC/SPC

FC/APC

FC/UPC

SC/SPC

SC/APC

SC/UPC

ST/SPC

ST/UPC

LC/SPC

LC/UPC

MU/UPC

None

1 meter

Specify X meters

Wavelength range

Attenuation range

Attenuation resolution

Monotonicity

Minimum insertion loss

1525.0nm to 1575.0 nm

30 dB

0.1 dB

> 0 dB/step

0.6 dB max.

Network Attenuator

DiCon’s Network Attenuator is a stepper motor-based compo-

nent which is used to adjust power levels in DWDM network

transmission systems. It features a novel shutter design,

which can be customized to provide any arbitrary relationship

between insertion loss and control voltage.

-9-

Temperature dependence 0.15 dB max.

of attenuation

Flatness

Ripple

PDL

PMD

Back-reflection

Response speed

Repeatability of

Attenuation setting

Fiber type

Fiber jacket

Optical power

Operating temperature

Storage temperature

10 dB

10 to 30 dB

0.05 dB max.

10 dB attenuation

0.10 ps max.

-55 dB max.

100 ms max.

0.1 dB max.

9/125 Corning SMF-28

900 micron, tight buffer

300 mW max.

-5 °C to + 70 °C

-40 °C to + 85 °C

0.1 dB max.

0.2 dB max.

0.10 dB max.

Connector Type

10 to 30 dB attenuation 0.15 dB max.

Pigtail Length

Features

•

Low polarization dependent loss and wavelength flatness over the

entire attenuation range

•

Standard model features ultra-linear response function

•

Customer-specified attenuation range and response function

•

Optional input and output monitors

Housing Dimensions

1. All specifications referenced without connectors.

2. Tapless model.

3. Relative to 23

°C.

Network Attenuators are used to adjust gain tilt in erbium-doped

fiber amplifiers. Network attenuators can also be used for signal

pre-emphasis of WDM lasers in long haul systems as well as power

equalization in optical add/drop multiplexers and optical cross con-

nects.

Units: mm

DiCon Fiberoptics, Inc. 1689 Regatta Blvd. Richmond, CA 94804

Tel. (510)528-0427

Fax. (510)525-5776

www.diconfiber.com

Attenuators

Applications

Network Attenuator
