57145,57150 Actuator
59145 and 59150 Flange Mount Features and Benefits
F eatures
•
2 Part Magnetically Operated
Benefits
•
No standby power requirement
•
Operates through non-ferrous
Applications
•
Position and limit sensing
•
Security system switch
•
Linear actuators
•
Door switch
59145,59150 Sensor
Proximity Sensor
•
Flying leads can exit either left or
right hand side of the housing
•
Case design allows screw down
or adhesive mounting
•
300mm (12”) Flying leads
materials such as wood,plastic or
aluminium
•
Hermetically sealed,magnetically
operated contacts continue to
operate long after optical and
other technologies fail due to
contamination
•
Simple installation and adjustment
DIMENSIONS
Recommended Activating Positions:
Sensors and Matching Actuators (Note 2)
Must
Actuate
.225 (5,71)
.225 (5,71)
Must
Release
.800 (20,32)
.800 (20,32)
Actuator
Sensor
57145-000
57150-000
59145-010
59150-010
59145-020
59150-020
59145-030
59150-030
59145-040
59150-040
Electrical Specifications and Operating Characteristics
Contact Type
Contact Rating
Voltage
Switching
Breakdown
Current
Switching
Carry
Resistance
Contact,Initial
Insulation
Capacitance
Temperature
Contact
Operating
Storage
Time
Operate
Release
Shock
Vibration
11ms 1⁄2 sine
50-2000 Hz
Watt - max.
Vdc - max.
Vdc - min.
A - max.
A - max.
Ω
- max.
Ω
- min.
p F - typ.
°C
°C
ms - typ.
ms - typ.
G - max.
G - max.
Form A
SPST-NO
F orm A
SPST-NO
F orm C
SPDT-CO
Form B
SPST-NC
Standar d
10
200
250
0.5
1.2
0.2
10
10
High Volta ge
10
300
450
0.5
1.5
0.2
10
10
Standar d
5
175
200
0.25
1.5
0.2
10
9
Standar d
5
175
200
0.25
1.5
0.2
10
9
0.3
-40 to + 105
-65 to + 105
1.0
1.0
50
30
0.3
-40 to + 105
-65 to + 105
1.0
1.0
100
30
0.2
-20 to + 105
-65 to + 105
1.0
1.0
100
30
0.3
-40 to + 105
-65 to + 105
1.0
1.0
50
30
Notes:
1.Flying Leads except as shown below are 24 AWG 7/32 PVC , 105 deg. C.,UL 1569.Leads are stripped .250 (6,35),
untinned.
2.Order Actuators as a separate item.
3.
Underwriters Laboratories recognition. For details on electrical specifications,contact Hamlin,Inc.
Breed Electronics USA
Breed Electronics UK
Tel: 001 920 648 3000
•
Fax:001 920 648 3001
•
Email: sales@hamlin.com
Tel: +44 (0)1379 649700
•
Fax:+44 (0)1379 649702
•
Email: uksales@breedtech.com
Breed Electronics German y
Tel: +49 (0) 6181 953660
•
Fax:+49 (0) 6181 9536666
•
Email: hamlin-electronics.de@breedtech.com
Breed Electronics France
Tel: +33 1 46 87 02 02
•
Fax:+33 1 46 86 67 86
•
Email: hamectrol@hamectrol.fr
INFORMATION PROVIDED ON THIS DATA SHEET IS PROVIDED FOR
INFORMATION PURPOSES ONLY AND SHOULD NOT BE RELIED
UPON AS BEING ACCURATE FOR ANY PARTICULAR PURPOSE.
Product performance may be affected by the application to which the
product is put. Upon request,HAMLIN will assist purchasers by providing
information specific to any particular application.HAMLIN disclaims any
and all liability whatsoever for any purchaser’s reliance upon the
information contained on this data sheet without further consultation with
authorised representatives of HAMLIN.
PA GE 1 OF 1
ISSUE No:1
DATE:08/12/00
SIGNED:Antony Howell
