Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2005-07-15
749013020
A
Mechanische Abmessungen / dimensions :
A
B
C
D
B
100 BaseT PoE
12,95 ± 0,25
7,11 ± 0,25
18,80 ± 0,25
15,75 ± 0,25
mm
mm
mm
mm
A
WE
D
P/N
YYWW
C
@@FRM 1@@
= Pin 1
B
Elektrische Eigenschaften / electrical properties :
Eigenschaften /
properties
Indukivität /
Inductance
Übersetzungsverhältnis
/ Turns ratio
C
Lötpad / soldering spec. :
Einheit / unit
tol.
min.
3%
15,75
11 x 0,99
10,90
Version 3
Version 2
Version 1
Änderung / modification
19,56
Testbedingungen /
test conditions
100kHz / 100mV @ 8mA DC-
Bias
100kHz / 100mV
1-100MHz
1-30MHz @ 100Ω
40MHz @ 100Ω
50MHz @ 100Ω
60-80MHz @ 100Ω
30MHz
60MHz
100MHz
60MHz
100MHz
Wert / value
OCL
TR
350
1:1
1:1
µH
Tx
Rx
Insertion Loss
IL
RL
-1,2
-16
-14
-13
-10
-50
-43
-35
-37
-33
dB
dB
max.
24 x 0,64
Return Loss
min.
Differential to Common
Mode Rejection
Crosstalk
DCMR
CT
dB
dB
min.
min.
D
Prüfgeräte / test equipment :
HP4395A
E
Testbedingungen / test conditions :
Luftfeuchtigkeit / humidity:
Umgebungstemperatur / temperature:
33%
+25°C
F
Werkstoffe & Zulassungen / material & approvals :
Basismaterial / base material:
Draht / wire:
Kontaktmaterial/ contact plating
Gehäuse / case
Verguss / potting
Ferrit/ ferrite
4UEW 155°C
Cu-Ni-Sn
UL94-V0
UL94-V0
G
Eigenschaften / general specifications :
Betriebstemp. / operating temperature: 0°C - + 70°C
Umgebungstemp. / ambient temperature:
Hochspannungsprüfung / Hipot test: 1500Vrms 1min.
Stromtragfähigkeit / Current capability: 350mA
geeignet für PoE-Anwendungen gemäß IEEE 802.3af /
Compliant with IEEE 802.3af for PoE-Applications
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
..................................................
TBr
TBr
2005-07-15
2004-11-19
2004-06-04
...............................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 1 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2005-07-15
749013020
H
Schaltbild / Schematics :
RD1+
1
24
RX1+
RCT1
2
23
RXCT1
RD1-
3
22
RX1-
TD1+
4
21
TX1+
TCT1
5
20
TXCT1
TD1-
6
19
TX1-
TD2+
7
18
TX2+
TCT2
8
17
TXCT2
TD2-
9
16
TX2-
RD2+ 10
15
RX2+
RCT2 11
14
RXCT2
RD2- 12
13
RX2-
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
..................................................
TBr
TBr
Version 3
Version 2
Version 1
Änderung / modification
2005-07-15
2004-11-19
2004-06-04
...............................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 2 VON 3
Spezifikation für Freigabe / specification for release
Kunde / customer
:
Artikelnummer / part number
:
Bezeichnung :
description :
LAN-Übertrager WE-LAN
LAN-Transformer WE-LAN
DATUM / DATE : 2005-07-15
749013020
I
Rollenspezifikation / tape and reel specification :
øC
D
E
F
Gurtspezifikation / Tape specification:
A
B
C
W
19,5
24,0
1,50
4,00
2,00
1,75
11,5
14,1
6,1
24,0
± 0,1
± 0,2
+ 0,1
- 0,0
mm
mm
mm
mm
mm
mm
mm
mm
mm
mm
G
A
B
H
D
E
F
G
H
I
W
± 0,1
± 0,1
± 0,1
± 0,1
± 0,1
± 0,1
± 0,1
I
a
b
d
Rollenspezifikation / Reel specification:
a
330,0 ± 2,0
mm
21,00 ± 0,8
mm
b
c
13,50 ± 0,5
mm
d
100,0 ± 1,0
mm
Øc
165 to 180°
The force for tearing off cover tape is
10 to 130 grams in arrow direction
feeding direction
Freigabe erteilt / general release:
Kunde / customer
..................................................................................
..................................................................................
Datum / date
Unterschrift / signature
Würth Elektronik
..................................................
TBr
TBr
Version 3
Version 2
Version 1
Änderung / modification
2005-07-15
2004-11-19
2004-06-04
...............................................
TBr
Name
Geprüft / checked
Kontrolliert / approved
Datum / date
This electronic component is designed and developed with the intention for use in general electronics equipments. Before incorporating the components into any equipments in the field such as aerospace, aviation, nuclear
control, submarine, transportation, (automotive control, train control, ship control), transportation signal, disaster prevention, medical, public information network etc. where higher safety and reliability are especially required
or if there is possibility of direct damage or injury to human body. In addition, even electronic component in general electronic equipments, when used in electrical circuits that require high safety, reliability functions or
performance, the sufficient reliability evaluation-check for the safety must be performed before use. It is essential to give consideration when to install a protective circuit at the design stage.
Würth Elektronik eiSos GmbH & Co.KG
D-74638 Waldenburg · Max-Eyth-Straße 1 - 3 · Germany · Telefon (+49) (0) 7942 - 945 - 0 · Telefax (+49) (0) 7942 - 945 - 400
http://www.we-online.com
SEITE 3 VON 3
