5650365-2 Product Details
Live Product Chat
AMP-HDI (Four Beam) & TBC (Twin Beam) Connectors
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
No Im a ge Ava ila ble
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5650365-2
T E I nternal N umber: 5 6 5 0 3 6 5 - 2
Product Highlights:
l
C onnector
l
Plug
l
Number of Positions = 120
l
Module Type = C enter
l
PC B Mount Style = Through Hole
View all Features
Obsolete
C ontact Product Information
C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
ASSEMBLY, PIN, C ENTER MODULE, RIGHT ANGLE, TBC +, LE...
(PDF, English)
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= C onnector
l
Gender
= Plug
l
Number of Positions
= 120
l
PC B Mount Style
= Through Hole
l
PC B Mount Angle
= Right Angle
l
Make First / Break Last
= Yes
l
Mating Polarization
= With
l
PC B Retention Feature
= No
l
Mating Polarization Type = Keying System
Mechanical Attachment:
l
Module Type
= C enter
Termination Related Features:
l
Termination Post Length (mm [in])
= 4.57 [0.180]
l
Solder Tail C ontact Plating
= Tin
Body Related Features:
l
Number of Rows = 6
l
C enterline (mm [in])
= 2.54 [0.100]
Contact Related Features:
l
C ontact Type
= Twin-Beam
l
C ontact Mating Area Plating Material
= Gold (30)
l
C ontact Base Material = Phosphor Bronze
l
C ontact Underplating = Nickel
Housing Related Features:
l
Housing Material = Polyester GF
l
Housing C olor = Black
l
Housing Flammability Rating = UL 94V-0
Configuration Related Features:
l
C enter Guide = Without
Industry Standards:
l
Government/Industry Qualification = No
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
