5646806-1 Product Details
Live Product Chat
2mm Hard Metric PCB Mount Connectors (Z-PACK 2mm
HM)
Always EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
5646806-1
T E I nternal N umber: 5 6 4 6 8 0 6 - 1
Product Highlights:
l
C onnector
l
C onnector Type = Header - Pin
l
Type = Type E
l
Interface Type = 2mm HM
l
C ontact Type = AC TION PIN Post
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Obsolete
C ontact Product Information C enter
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
None Available
Catalog Pages/Data Sheets:
l
None Available
Product Specifications:
l
C onnector, Z-PAC K, 8 Row, 2mm HM
(PDF, English)
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type = C onnector
l
C onnector Type = Header - Pin
l
Number of Positions
= 225
l
PC B Mount Angle
= Vertical
l
Mating Polarization
= Without
l
Shielded
= No
Mechanical Attachment:
l
Board Mount
= Free Board
l
Module Length (mm [in]) = 49.90 [1.966]
Termination Related Features:
l
Interface Type
= 2mm HM
l
Termination End Plating = Tin over Nickel
Body Related Features:
l
Type = Type E
l
Number of Rows
= 10
l
Grounding C ontact
= Without
l
Selectively Loaded = See Print for Loaded Positions
Contact Related Features:
l
C ontact Type = AC TION PIN Post
l
Feedthrough Post Length (mm [in])
= 13.00 [0.512], 14.50 [0.571],
16.00 [0.630]
l
C ompactPC I
= No
l
C ontact Plating, Mating Area, Material
= Gold
l
C ontact Base Material = Phosphor Bronze
Housing Related Features:
l
Housing Material = Polyester GF
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Not relevant for lead free process
l
RoHS/ELV C ompliance History = Always was RoHS compliant
Other:
l
Brand = AMP
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
