MTR Series Triple, case F2 – compression glass seal
HUM40 – compression glass seal or ceramic seal
Case F3 – compression glass seal
Case F4 – compression glass seal or ceramic seal
Case dimensions in inches (mm)
Tolerance
±0.005
(0.13) for three decimal places
±0.01
(0.2) for two decimal places
unless otherwise specified
Dot on top of case indicates pin one
CASE F
BOTTOM VIEW
See Figures 20 - 23 for pin configuration
1.350 max
(34.29)
1.950 max
(49.53)
CAUTION
Heat from reflow or wave soldering may damage
the device. Solder pins individually with heat
application not exceeding 300°C for 10 seconds
per pin.
F
IGURE
19: C
ASE
F M
AXIMUM
D
IMENSIONS
BOTTOM VIEW CASE F1
MTR Series Triple and MHV Series Triple: Screening – Standard, ES, or 883
Bathtub
Platform
Dot on top of case indicates pin one
1.170
(29.72)
0.040 dia.
(1.02)
MHV
Series
MTR
Series
Seam Seal
1
2
3
4
5
10
0.170
(4.32)
0.000
0.25 (6.4)
0.405 max
(10.29)
0.000
0.000
0.170
(4.32)
9
8
7
6
0.570
(14.48)
0.970
(24.64)
1.370
(34.80)
0.405 max
(10.29)
Note: Although every effort has been made to render the case drawings at actual size, variations in the printing process may cause some distortion. Please refer
