SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
2N6537
DESCRIPTION
·With TO-66 package
·DARLINGTON
APPLICATIONS
·Power switching
·
Hammer drivers
·
Series and shunt regulators
·
Audio amplifiers
PINNING (See Fig.2)
PIN
1
2
3
Base
Emitter
Collector
Fig.1 simplified outline (TO-66) and symbol
DESCRIPTION
Absolute maximum ratings(Ta=25
)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
T
T
j
T
stg
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector current-Peak
Base current
Total power dissipation
Junction temperature
Storage temperature
T
C
=25
CONDITIONS
Open emitter
Open base
Open collector
VALUE
120
120
5
8
15
0.25
36
150
-65~150
UNIT
V
V
V
A
A
A
W
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
CHARACTERISTICS
Tj=25
unless otherwise specified
PARAMETER
Collector-emitter sustaining voltage
Collector-emitter saturation voltage
Collector-emitter saturation voltage
Base -emitter on voltage
Base -emitter on voltage
Collector cut-off current
Collector cut-off current
Emitter cut-off current
DC current gain
DC current gain
Diode forward voltage
CONDITIONS
I
C
=0.2A ; I
B
=0
I
C
=3A ;I
B
=6mA
I
C
=8A; I
B
=80mA
I
C
=3A ; V
CE
=3V
I
C
=8A ; V
CE
=3V
V
CE
=120V; V
BE
=-1.5V
T
C
=125
V
CE
=120V; I
B
=0
V
EB
=5V; I
C
=0
I
C
=3A ; V
CE
=3V
I
C
=8A ; V
CE
=3V
I
F
=5A
1000
100
MIN
120
TYP.
2N6537
SYMBOL
V
CEO(SUS)
V
CEsat-1
V
CEsat-2
V
BE-1
V
BE-2
I
CEV
I
CEO
I
EBO
h
FE-1
h
FE-2
V
F
MAX
UNIT
V
2.0
3.0
2.8
4.5
0.5
5.0
1.0
5.0
10000
5000
4.0
V
V
V
V
mA
mA
mA
V
2
