MUX-16ET datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> MUX-16ET

MUX-16ET: Description16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28; CategoryAnalog mixed-signal IC The signal circuit; File Size4MB，11 Pages; ManufacturerRochester Electronics; Websitehttps://www.rocelec.com/

Download Datasheet Parametric View All

MUX-16ET Overview

16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERDIP-28

MUX-16ET Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	DIP
package instruction	DIP,
Contacts	28
Reach Compliance Code	unknown
Analog Integrated Circuits - Other Types	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-GDIP-T28
JESD-609 code	e0
Humidity sensitivity level	NOT SPECIFIED
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	16
Number of functions	1
Number of terminals	28
Nominal off-state isolation	66 dB
On-state resistance matching specifications	20.3 Ω
Maximum on-state resistance (Ron)	380 Ω
Maximum operating temperature	85 °C
Minimum operating temperature	-25 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
Maximum seat height	5.72 mm
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	500 ns
Maximum connection time	2000 ns
technology	BIPOLAR
Temperature level	OTHER
Terminal surface	TIN LEAD
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	15.24 mm
Base Number Matches	1
