SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
2SC4064
DESCRIPTION
·With TO-220F package
·Complement to type 2SA1567
·Low collector saturation voltage
APPLICATIONS
·For DC motor driver and general purpose
PINNING
PIN
1
2
3
Base
Collector
Emitter
Fig.1 simplified outline (TO-220F) and symbol
DESCRIPTION
Absolute maximum ratings (Ta=25 )
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
B
P
C
T
j
T
stg
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Base current
Collector power dissipation
Junction temperature
Storage temperature
T
C
=25
CONDITIONS
Open emitter
Open base
Open collector
VALUE
50
50
6
12
3
35
150
-55~150
UNIT
V
V
V
A
A
W
SavantIC Semiconductor
Product Specification
Silicon NPN Power Transistors
CHARACTERISTICS
Tj=25
unless otherwise specified
PARAMETER
Collector-emitter breakdown voltage
Collector-emitter saturation voltage
Collector cut-off current
Emitter cut-off current
DC current gain
Transition frequency
Output capacitance
CONDITIONS
I
C
=25mA; I
B
=0
I
C
=6A;I
B
=0.3 A
V
CB
=50V; I
E
=0
V
EB
=6V; I
C
=0
I
C
=6A ; V
CE
=1V
I
C
=0.5A ; V
CE
=12V
I
E
=0; V
CB
=10V;f=1MHz
50
40
MIN
50
2SC4064
SYMBOL
V
(BR)CEO
V
CEsat
I
CBO
I
EBO
h
FE
f
T
C
OB
TYP.
MAX
UNIT
V
0.35
100
10
V
µA
µA
MHz
pF
180
Switching times
t
on
t
s
t
f
Turn-on time
Storage time
Fall time
I
C
=6A;R
L
=4@
I
B1
=- I
B2
=0.12A
V
CC
=24V
0.60
1.40
0.40
µs
µs
µs
2
