SMD INDUCTOR DR331-4 SERIES
Features
Low Profile Surface Mount Design
Inductance Range from 1.0µH to 1000µH
Operating Temp. -40°C to +85°C
Tinned Leads with Leaded Solder is Available
(note 6)
ELECTRICAL SPECIFICATIONS 25°C
Inductance (µH)
±20%
1
2.2
3.3
5.6
10
15
22
33
47
68
100
150
220
330
470
680
1000
DCR
(Ω) Max.
0.009
0.014
0.018
0.020
0.031
0.036
0.047
0.066
0.086
0.13
0.19
0.25
0.38
0.56
0.85
1.1
1.8
I rms (A)
Max. (Note 3)
8.6
7.1
6.2
5.3
4.3
4
3.5
3
2.6
2.3
1.8
1.5
1.2
1.0
0.82
0.72
0.56
I sat (A)
Max. (Note 2)
20
16
14
12
10
8
7
5.5
4.5
3.5
3
2.6
2.4
1.9
1.4
1.2
1.0
SRF
(MHz) REF.
80
80
60
40
30
22
20
15
9.0
8.0
7.0
6.0
5.0
4.0
3.0
2.5
2.0
Part No.
DR331-4-102
DR331-4-222
DR331-4-332
DR331-4-562
DR331-4-103
DR331-4-153
DR331-4-223
DR331-4-333
DR331-4-473
DR331-4-683
DR331-4-104
DR331-4-154
DR331-4-224
DR331-4-334
DR331-4-474
DR331-4-684
DR331-4-105
MECHANICAL SPECIFICATIONS
331-4
XXX
1
.729 MAX.
18,54
2
1
2
SCHEMATIC
.279 MAX.
7,11
NOTES:
1. Dimensions are shown in inches/millimeters
Unless otherwise specified, tolerance
= Inches: ±0.010
= Millimeters: ±0,25
2. Isat based on the inductance being 90% of
its initial value
3. Irms based on temperature rise of 40°C
4. Tape & Reel Packaging, 400 pcs / reel.
5. Inductance tested at 0.1 Vrms @ 100 kHz
6. For non-RoHS parts replace DR prefix with
42- (e.g. DR331-4 becomes 42-331-4)
7. Terminal finish is compliant to RoHS
requirements. Solder in accordance with J-
STD-020C.
.100
2,54
.490
12,45
.114
2,92
.109
2,79
.600 MAX.
15,24
.500
12,70
SUGGESTED PAD LAYOUT
