REVISION S
DO NOT
SCALE FROM
THIS PRINT
C
LS2-1XX-XX-XX-D-XXX-X
No OF POSITIONS
-05, -10, -15, -20,
-25, -30
(PER ROW)
((No OF POS x .07874[2.0000])
+.0618[1.570]) .010[.25]
(No OF POS -1) x .07874[2.0000] REF
LEAD STYLE
-01: THROUGH HOLE
-02: SURFACE MOUNT
(SEE FIG 2)
PLATING SPECIFICATION
-F: FLASH SELECTIVE GOLD
(USE T-1S13-XX-F-2 & C-79-XX-F)
-FM: FLASH SELECTIVE GOLD
MATTE TIN REMAINDER
(USE T-1S13-XX-F-2 & C-79-XX-F)
-L: LIGHT SELECTIVE GOLD
(USE T-1S13-XX-L-2 & C-79-XX-L)
-LM: LIGHT SELECTIVE GOLD
MATTE TIN REMAINDER
(USE T-1S13-XX-L-2 & C-79-XX-L)
-S: SELECTIVE GOLD
(USE T-1S13-XX-S-2 & C-79-XX-S)
-SM: SELECTIVE GOLD
MATTE TIN REMAINDER
(USE T-1S13-XX-S-2 & C-79-XX-S)
-G: GOLD
(USE T-1S13-XX-G-2 & C-79-XX-G)
-H: HEAVY GOLD
(USE T-1S13-XX-H-2 & C-79-XX-H)
TERMINAL
.104 2.642
REF
OPTION
-K: POLYIMIDE FILM PAD
(USE K-DOT-.246-.375-.005, SEE FIG 5)
[LEAD STYLE -02 ONLY]
-A: ALIGNMENT PIN
(USE LS2-XX-D-XX-A, SEE FIG 6)
[LEAD STYLE -02 ONLY]
-TR: TAPE & REEL
"A"
.0787 2.000 REF
02
.2075 5.270
REF
TAIL OPTION
-RA1: RIGHT ANGLE-
SHROUD DOWN (SEE FIG 3)
-RA2: RIGHT ANGLE-
SHROUD UP (SEE FIG 4)
[AVAILABLE ONLY ON LEAD STYLE -01]
ROW SPECIFICATION
-D: DOUBLE (USE LS2-XX-D-XX)
"A"
01
SEE NOTE 6
LS2-110-01-X-D SHOWN
FIG 1
LS2-XX-D-XX
CONTACT
.250 6.35
REF
.090 2.286
C
C
2 MAX SWAY
(TYP)
.0197 0.500 SQ
REF (TYP)
(No OF POS -1) x .07874[2.0000])
.006[.15]
C
2 MAX SWAY
(TYP)
.0787±.0050 2.000±0.127 (TYP)
C
C
.0787±.0050 2.000±0.127 (TYP)
C
SECTION "A"-"A"
NOTES:
1.
C
REPRESENTS A CRITICAL DIMENSION.
2. BURR ALLOWANCE: .003[.08] MAX.
3. MAXIMUM CUT FLASH: .015[.38].
4. MINIMUM PUSHOUT FORCE; TERMINALS: 2 LBS, CONTACTS: .5 LBS.
5. MAXIMUM ALLOWABLE BOW: .002 INCH/INCH AFTER ASSEMBLY.
6. SEE APPLICATION VIEWS (SHEET 3) FOR POSITION 01 LOCATION.
7. ALL PIN TO PIN DIMENSIONS TO BE MEASURED FROM TIP TO TIP.
8. DIMENSION TO BE MEASURED AT BEND.
9. SHEAR TAILS TO DIMENSION SHOWN.
UNLESS OTHERWISE SPECIFIED,
DIMENSIONS ARE IN INCHES.
TOLERANCES ARE:
DECIMALS
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
.XX: .01 [.3]
2
.XXX: .005 [.13]
.XXXX: .0020 [.051]
ANGLES
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
MATERIAL:
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
INSULATOR: LCP, COLOR: BLACK
SOCKET: PHOS BRONZE
TERMINAL: PHOS BRONZE
2mm TERMINAL/SOCKET COMBO
LS2-1XX-XX-XX-D-XXX-X
4/24/2002
SHEET
1
OF
4
F:\DWG\MISC\MKTG\LS2-1XX-XX-XX-D-XXX-X-MKT.SLDDRW
BY:
DEAN P
REVISION S
"B"
LS2-110-02-X-D SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG. 1]
FIG 2
TERMINAL
CONTACT
PACKAGING VIEWS
STYLE -01
STYLE -02
90°
- 4°
+0°
.10 2.6
REF
.330 8.38
C
(SEE NOTE 8)
.0060[.152]
"B"
2 MAX SWAY
(TYP)
.031 0.78
.269±.010 6.83±0.25
SECTION "B"-"B"
STYLE -02-D IN-PROCESS VIEWS
IN-PROCESS 1
IN-PROCESS 2
IN-PROCESS 3
TUBE: PT-1-24-04-09
PLUG: TP-07
TUBE: PT-1-24-01-123
PLUG: TP-03
STYLE -01-RA1
STYLE -01-RA2
.223 5.66
.155±.005 3.94±0.127
(SEE NOTE 9)
.600 15.24
LS2-XX-D-XX-A
FIG 6
-A: ALIGNMENT PIN OPTION
LS2-110-02-X-D-A SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 2]
TUBE: PT-1-24-01-124
PLUG: TP-07
TUBE: PT-1-24-01-124
PLUG: TP-07
PROPRIETARY NOTE
.035 0.893
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
2mm TERMINAL/SOCKET COMBO
4/24/2002
SHEET
2
OF
4
(No OF POS x .07874[2.0000])
- .15748[4.0000] REF
.035 0.89 REF
F:\DWG\MISC\MKTG\LS2-1XX-XX-XX-D-XXX-X-MKT.SLDDRW
LS2-1XX-XX-XX-D-XXX-X
BY:
DEAN P
REVISION S
IN-PROCESS 1
IN-PROCESS 2
IN-PROCESS 1
IN-PROCESS 4
.183 4.65 REF
.302 7.67
.070 1.78
(SEE NOTE 8)
.323 8.21 REF
90°
.149 3.78
90°
.600 15.24
STYLE -01-RA1 IN-PROCESS VIEWS
.945 24.00
REF
TERMINAL
CONTACT
.090±.010 2.29±0.25
(SEE NOTE 9)
2 MAX SWAY
(TYP)
.079 2.00 (SEE NOTE 7)
.070 1.78 (SEE NOTE 8)
C
1.732 44.00
REF
90°
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
FIG 3
LS2-110-01-X-D-RA1 SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1]
* AVAILABLE ONLY ON LEAD STYLE -01 *
APPLICATION VIEWS
BOARD
B
02
02
02
01
01
01
02
02
02
PROPRIETARY NOTE
01
01
STYLE-01-RA1 PACKAGING VIEW
PARTS MUST BE ORIENTED PER THE DESIGN
OF THE POCKET AND POCKET TOOL.
POCKETS DESIGNED AFTER REVISION Q MUST
ORIENT PARTS PER THIS VIEW.
BOARD
A
PARALLEL
BOARD-TO-BOARD
BOARD
A
PERPENDICULAR
BOARD-TO-BOARD
BOARD
B
-RA1
-RA2
IN-LINE PARALLEL
BOARD-TO-BOARD
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
SHEET SCALE: 3:1
2mm TERMINAL/SOCKET COMBO
LS2-1XX-XX-XX-D-XXX-X
4/24/2002
SHEET
3
OF
4
F:\DWG\MISC\MKTG\LS2-1XX-XX-XX-D-XXX-X-MKT.SLDDRW
BY:
DEAN P
REVISION S
IN-PROCESS 1
IN-PROCESS 2
IN-PROCESS 3
IN-PROCESS 4
.162 4.11 REF
.600 15.24
90°
.481 12.21 REF
90°
.440 11.18
.070 1.78
.149 3.78
STYLE -01-RA2 IN-PROCESS VIEWS
TERMINAL
CONTACT
.945 24.00
REF
.090±.010 2.29±0.25
(SEE NOTE 9)
2 MAX SWAY
(TYP)
LS2-110-01-X-D-RA2 SHOWN
[DIFFERENT AS SHOWN, OTHERWISE SAME AS FIG 1]
* AVAILABLE ONLY ON LEAD STYLE -01 *
.079 2.00 (SEE NOTE 7)
.070 1.78 (SEE NOTE 8)
C
1.732 44.00
REF
FIG 4
90°
USER DIRECTION OF UN-REELING
POCKET NOT DETAILED
FIG 5
-K: POLYIMIDE FILM PAD OPTION
"R" REF
"S"±.020 [.51]
.019±.010 0.49±0.25
PROPRIETARY NOTE
THIS DOCUMENT CONTAINS INFORMATION
CONFIDENTIAL AND PROPRIETARY TO
SAMTEC, INC. AND SHALL NOT BE REPRODUCED
OR TRANSFERRED TO OTHER DOCUMENTS OR
DISCLOSED TO OTHERS OR USED FOR ANY
PURPOSE OTHER THAN THAT WHICH IT WAS
OBTAINED WITHOUT THE EXPRESSED WRITTEN
CONSENT OF SAMTEC, INC.
PARTS MUST BE ORIENTED PER THE DESIGN
OF THE POCKET AND POCKET TOOL.
POCKETS DESIGNED AFTER REVISION Q MUST
ORIENT PARTS PER THIS VIEW.
STYLE-01-RA2 PACKAGING VIEW
520 PARK EAST BLVD, NEW ALBANY, IN 47150
PHONE: 812-944-6733
FAX: 812-948-5047
e-Mail: info@SAMTEC.com
code: 55322
DESCRIPTION:
DWG. NO.
DO NOT SCALE DRAWING
NOTE:
"R" = (No OF POS x .07874[2.0000]) +.06181[1.570]
"S" = ("R" - .2460[6.248]) / 2
.246 6.25 REF
2mm TERMINAL/SOCKET COMBO
.335 8.51
F:\DWG\MISC\MKTG\LS2-1XX-XX-XX-D-XXX-X-MKT.SLDDRW
SHEET SCALE: 3:1
LS2-1XX-XX-XX-D-XXX-X
4/24/2002
