Z8601840ASC datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The embedded processor and controller> Microcontrollers and processors> Z8601840ASC

Z8601840ASC: DescriptionFixed Disk Controller, 4.125MBps, IDE Compatible, CMOS, PQFP100, PLASTIC, VQFP-100; CategoryThe embedded processor and controller Microcontrollers and processors; File Size57KB，1 Pages; ManufacturerZilog, Inc.; Websitehttps://www.zilog.com/

Download Datasheet Parametric Compare View All

Z8601840ASC Overview

Fixed Disk Controller, 4.125MBps, IDE Compatible, CMOS, PQFP100, PLASTIC, VQFP-100

Z8601840ASC Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Parts packaging code	QFP
package instruction	QFP, QFP100,.63SQ,20
Contacts	100
Reach Compliance Code	unknown
maximum clock frequency	40 MHz
Maximum data transfer rate	4.125 MBps
Drive interface standards	IDE
External data bus width	16
Maximum host data transfer rate	7 MBps
Host interface standard	PC-AT
JESD-30 code	S-PQFP-G100
JESD-609 code	e0
Number of terminals	100
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	QFP
Encapsulate equivalent code	QFP100,.63SQ,20
Package shape	SQUARE
Package form	FLATPACK
Peak Reflow Temperature (Celsius)	240
power supply	5 V
Certification status	Not Qualified
Maximum slew rate	45 mA
Maximum supply voltage	5.25 V
Minimum supply voltage	4.75 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	0.5 mm
Terminal location	QUAD
Maximum time at peak reflow temperature	NOT SPECIFIED
uPs/uCs/peripheral integrated circuit type	SECONDARY STORAGE CONTROLLER, FIXED DISK
Base Number Matches	1

Preview

Download Datasheet

View All

Z8601840ASC Related Products

	Z8601840ASC	Z86C9524VSCXXXX	Z8629540FSCXXXX	Z8619340ASCXXXX	Z8629540ASCXXXX	Z8629540FSC
Description	Fixed Disk Controller, 4.125MBps, IDE Compatible, CMOS, PQFP100, PLASTIC, VQFP-100	Digital Signal Processor, 0-Ext Bit, 24MHz, CMOS, PQCC84, PLASTIC, LCC-84	Digital Signal Processor, 0-Ext Bit, 40MHz, CMOS, PQFP144, PLASTIC, QFP-144	Microcontroller, 8-Bit, 40MHz, CMOS, PQFP64, PLASTIC, VQFP-64	Digital Signal Processor, 0-Ext Bit, 40MHz, CMOS, PQFP100, VQFP-100	Digital Signal Processor, 0-Ext Bit, 40MHz, CMOS, PQFP144, PLASTIC, QFP-144
Parts packaging code	QFP	LCC	QFP	QFP	QFP	QFP
package instruction	QFP, QFP100,.63SQ,20	QCCJ,	QFP,	LFQFP,	LFQFP,	QFP,
Contacts	100	84	144	64	100	144
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
maximum clock frequency	40 MHz	24 MHz	40 MHz	40 MHz	40 MHz	40 MHz
JESD-30 code	S-PQFP-G100	S-PQCC-J84	S-PQFP-G144	S-PQFP-G64	S-PQFP-G100	S-PQFP-G144
Number of terminals	100	84	144	64	100	144
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	QFP	QCCJ	QFP	LFQFP	LFQFP	QFP
Package shape	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE	SQUARE
Package form	FLATPACK	CHIP CARRIER	FLATPACK	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK, LOW PROFILE, FINE PITCH	FLATPACK
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	YES	YES	YES	YES	YES	YES
technology	CMOS	CMOS	CMOS	CMOS	CMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	GULL WING	J BEND	GULL WING	GULL WING	GULL WING	GULL WING
Terminal pitch	0.5 mm	1.27 mm	0.65 mm	0.5 mm	0.5 mm	0.65 mm
Terminal location	QUAD	QUAD	QUAD	QUAD	QUAD	QUAD
uPs/uCs/peripheral integrated circuit type	SECONDARY STORAGE CONTROLLER, FIXED DISK	DIGITAL SIGNAL PROCESSOR, OTHER	DIGITAL SIGNAL PROCESSOR, OTHER	MICROCONTROLLER	DIGITAL SIGNAL PROCESSOR, OTHER	DIGITAL SIGNAL PROCESSOR, OTHER
Address bus width	-	16	16	-	16	16
barrel shifter	-	NO	NO	-	NO	NO
boundary scan	-	NO	NO	-	NO	NO
Format	-	FIXED POINT	FIXED POINT	-	FIXED POINT	FIXED POINT
Internal bus architecture	-	SINGLE	SINGLE	-	SINGLE	SINGLE
length	-	29.3116 mm	28 mm	10 mm	14 mm	28 mm
low power mode	-	YES	YES	-	YES	YES
Maximum seat height	-	4.57 mm	4.07 mm	1.6 mm	1.6 mm	4.07 mm
width	-	29.3116 mm	28 mm	10 mm	14 mm	28 mm
Maker	-	-	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.
ECCN code	-	-	3A991.A.2	3A991.A.2	3A991.A.2	3A991.A.2
