Z861505PSCXXXX: DescriptionMicrocontroller, 8-Bit, MROM, 5MHz, NMOS, PDIP40, PLASTIC, DIP-40; CategoryThe embedded processor and controller Microcontrollers and processors; File Size45KB，1 Pages; ManufacturerZilog, Inc.; Websitehttps://www.zilog.com/

Download Datasheet Parametric Compare View All

Z861505PSCXXXX Overview

Microcontroller, 8-Bit, MROM, 5MHz, NMOS, PDIP40, PLASTIC, DIP-40

Z861505PSCXXXX Parametric

Parameter Name	Attribute value
Parts packaging code	DIP
package instruction	DIP,
Contacts	40
Reach Compliance Code	unknown
Has ADC	NO
bit size	8
maximum clock frequency	5 MHz
DAC channel	NO
DMA channel	NO
JESD-30 code	R-PDIP-T40
length	52.325 mm
Number of I/O lines	32
Number of terminals	40
Maximum operating temperature	70 °C
Minimum operating temperature
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
ROM programmability	MROM
Maximum seat height	4.96 mm
speed	5 MHz
surface mount	NO
technology	NMOS
Temperature level	COMMERCIAL
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
width	15.24 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER
Base Number Matches	1

Preview

Download Datasheet

Z861505PSCXXXX Related Products

	Z861505PSCXXXX	Z861505VSCXXXX	Z861404PSCXXXX	Z861504PSC	Z861504PSCXXXX	Z861504VSCXXXX	Z861504VSC	Z860204VSCXXXX	Z860204PSCXXXX	Z86E2304VSCXXXX
Description	Microcontroller, 8-Bit, MROM, 5MHz, NMOS, PDIP40, PLASTIC, DIP-40	Microcontroller, 8-Bit, MROM, 5MHz, NMOS, PQCC44, PLASTIC, LCC-44	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PDIP40, PLASTIC, DIP-40	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PDIP40, PLASTIC, DIP-40	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PDIP40, PLASTIC, DIP-40	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PQCC44, PLASTIC, LCC-44	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PQCC44, PLASTIC, LCC-44	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PQCC44, PLASTIC, LCC-44	Microcontroller, 8-Bit, MROM, 4MHz, NMOS, PDIP40, PLASTIC, DIP-40	Microcontroller, 8-Bit, OTPROM, 4MHz, CMOS, PQCC44, PLASTIC, LCC-44
Parts packaging code	DIP	LCC	DIP	DIP	DIP	LCC	LCC	LCC	DIP	LCC
package instruction	DIP,	QCCJ,	DIP,	DIP,	DIP,	QCCJ,	QCCJ,	QCCJ,	DIP,	QCCJ,
Contacts	40	44	40	40	40	44	44	44	40	44
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknown	unknow
Has ADC	NO	NO	NO	NO	NO	NO	NO	NO	NO	NO
bit size	8	8	8	8	8	8	8	8	8	8
maximum clock frequency	5 MHz	5 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz
DAC channel	NO	NO	NO	NO	NO	NO	NO	NO	NO	NO
DMA channel	NO	NO	NO	NO	NO	NO	NO	NO	NO	NO
JESD-30 code	R-PDIP-T40	S-PQCC-J44	R-PDIP-T40	R-PDIP-T40	R-PDIP-T40	S-PQCC-J44	S-PQCC-J44	S-PQCC-J44	R-PDIP-T40	S-PQCC-J44
length	52.325 mm	16.5862 mm	52.325 mm	52.325 mm	52.325 mm	16.5862 mm	16.5862 mm	16.5862 mm	52.325 mm	16.5862 mm
Number of I/O lines	32	32	32	32	32	32	32	32	32	32
Number of terminals	40	44	40	40	40	44	44	44	40	44
Maximum operating temperature	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C	70 °C
Package body material	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY	PLASTIC/EPOXY
encapsulated code	DIP	QCCJ	DIP	DIP	DIP	QCCJ	QCCJ	QCCJ	DIP	QCCJ
Package shape	RECTANGULAR	SQUARE	RECTANGULAR	RECTANGULAR	RECTANGULAR	SQUARE	SQUARE	SQUARE	RECTANGULAR	SQUARE
Package form	IN-LINE	CHIP CARRIER	IN-LINE	IN-LINE	IN-LINE	CHIP CARRIER	CHIP CARRIER	CHIP CARRIER	IN-LINE	CHIP CARRIER
Certification status	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
ROM programmability	MROM	MROM	MROM	MROM	MROM	MROM	MROM	MROM	MROM	OTPROM
Maximum seat height	4.96 mm	4.57 mm	4.96 mm	4.96 mm	4.96 mm	4.57 mm	4.57 mm	4.57 mm	4.96 mm	4.57 mm
speed	5 MHz	5 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz	4 MHz
surface mount	NO	YES	NO	NO	NO	YES	YES	YES	NO	YES
technology	NMOS	NMOS	NMOS	NMOS	NMOS	NMOS	NMOS	NMOS	NMOS	CMOS
Temperature level	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL	COMMERCIAL
Terminal form	THROUGH-HOLE	J BEND	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	J BEND	J BEND	J BEND	THROUGH-HOLE	J BEND
Terminal pitch	2.54 mm	1.27 mm	2.54 mm	2.54 mm	2.54 mm	1.27 mm	1.27 mm	1.27 mm	2.54 mm	1.27 mm
Terminal location	DUAL	QUAD	DUAL	DUAL	DUAL	QUAD	QUAD	QUAD	DUAL	QUAD
width	15.24 mm	16.5862 mm	15.24 mm	15.24 mm	15.24 mm	16.5862 mm	16.5862 mm	16.5862 mm	15.24 mm	16.5862 mm
uPs/uCs/peripheral integrated circuit type	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER	MICROCONTROLLER
Maker	-	-	-	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.	Zilog, Inc.
