MASTER INSTRUMENT CORPORATION
SINGLE-PHASE BRIDGE RECTIFIER
2W005M THRU 2W10M
RC201 THRU RC207
FEATURES
l
Low cost
l
This series is UL recognized under component
index,file number E127707
l
High forward surge current capability
l
Ideal for printed circuit board
l
High temperature soldering guaranteed:
260
o
C/10 second, 0.375”(9.5mm) lead length
at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
l
Case: Molded plastic body
l
Terminal: Lead solderable per MIL-STD-202E
method 208C.
l
Polarity: Polarity symbols molded on case
l
Mounting position: Any
l
Weight:0. 05ounce, 1.42grams
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
1.5 Amperes
.366(9.3)
.350(8.8)
.290(7.4)
.270(6.9)
1.1
(27.9)
MIN
1.0
(25.4)
MIN
POS
LEAD
~
+
.032(0.8)DIA
.028(0.7)TYP
-
~
.220(5.6)
.180(4.6)
.220(5.6)
.180(4.6)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
2W005M 2W01M
RC201
RC202
50
35
50
100
70
100
2W02M
RC203
200
140
200
2W04M
RC204
400
280
400
1.5
50
10
1.0
5.0
0.5
C
J
R
θ
JA
T
J
T
STG
15
40
-55 to +150
-55 to +150
2W06M
RC205
600
420
600
2W08M 2W10M
RC206 RC207
800
560
800
1000
700
1000
SYMBOLS
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current, at T
A
=25℃
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Rating for Fusing(t<8.3ms)
Maximum Instantaneous Forward Voltage at 1.0A
Maximum DC Reverse Current at rated
DC blocking voltage
Typical Junction Capacitance(Note1)
Typical Thermal Resistance(Note2)
Operating Temperature Range
Storage Temperature Range
T
A
=25℃
T
A
=100℃
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
T
V
F
I
R
UNITS
Volts
Volts
Volts
Amps
Amps
A
2
S
Volts
µAmps
mAmps
P
F
℃/W
℃
℃
NOTES:
1.
Measured at 1.0MHz and applied reverse voltage of 4.0 volts.
2.
Unit mounted on P.C. board with 0.22”×0.22”(5.5×5.5mm)copper pads,0.375”(9.5mm)lead length.
E-mail:
sales@cnmic.com
Web Site: www.cnmic.com
1/2
