MASTER INSTRUMENT CORPORATION
SINGLE-PHASE BRIDGE RECTIFIER
BR1005 THRU BR1010
FEATURES
l
Low cost
l
This series is UL recognized under component
index, file number E127707
l
High forward surge current capability
l
Ideal for printed circuit board
l
High isolation voltage from case to leads
l
High temperature soldering guaranteed:
260
o
C/10 second, at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
l
Case: Molded plastic body
l
Terminal: Lead solderable per MIL-STD-202E
method 208C.
l
Polarity: Polarity symbols molded on case
l
Mounting: Thru hole for #6 screw, 5 in.-lbs torque max.
l
Weight:0. 20ounce, 5.62 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
SYMBOLS BR1005
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
T
C
=50℃(Note1)
Maximum Average Forward
Rectified Output Current, at T
C
=100℃(Note1)
T
A
=50℃(Note2)
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Rating for Fusing(t<8.3ms)
Maximum Instantaneous Forward Voltage at 5.0A
Maximum DC Reverse Current at rated T
A
=25
o
C
DC blocking voltage
T
A
=150
o
C
Isolation Voltage from case to leads
Typical Thermal Resistance (Note 1)
Operating Temperature Range
Storage Temperature Range
I
FSM
I
2
T
V
F
I
R
V
ISO
R
θJC
T
J
T
STG
V
RRM
V
RMS
V
DC
50
35
50
BR101
100
70
100
BR102
200
140
200
BR104
400
280
400
10.0
I
(AV)
6.0
6.0
150
93
1.1
5.0
1.0
2500
6.0
-55 to +150
-55 to +150
Amps
A
2
S
Volts
µAmps
mAmps
V
AC
℃/W
℃
℃
Amps
BR106
600
420
600
BR108
800
560
800
BR1010
1000
700
1000
UNITS
Volts
Volts
Volts
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
10 Amperes
0.52( 13.2)
0.48( 12.2)
0.07( 1.8) x45
+
AC
0.52( 13.2)
0.48( 12.2)
AC
-
0.77( 19.6)
0.73( 18.5)
0.16( 4.1)
0.14( 3.6) DIA
°
0.77( 19.6)
0.73( 18.5)
0.30( 7.6)
0.25( 6.4)
0.85( 21.6) MIN
0.75( 19.0) MIN
0.08( 2.0) MIN
0.052( 1.3) DIA.
0.048( 1.2) TYP.
Dimensions in inches and (millimeters)
NOTES:
1.
Unit mounted on 8.7”×8.7”×0.24” thick (22×22×0.6mm) Al. plate.
2.
Unit mounted on P.C.B at 0.375” (9.5mm) lead length with 0.47”×0.47” (12×12mm) copper pads.
E-mail:
sales@cnmic.com
Web Site: www.cnmic.com
1/2
