SINGLE PHASE BRIDGE RECTIFIER
FBPC25005WN THRU FBPC2510WN
FEATURES
•
•
•
•
•
•
•
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
25 Ampere
Low cost
This series is UL recognized under component
index file number E127707
High forward surge current capability
Fast switching for high efficiency
Integrally molded heatsink provide
very low thermal resistance
High isolation voltage from case to leads
High temperature soldering guaranteed:
260℃ / 10 seconds,at 5 lbs. (2.3kg) tension.
0.732(18.6)
0.692(17.6)
1.13(28.8)
0.47(11.9) 1.11(28.2)
0.43(10.9)
0.205(5.2)
0.197(5.0)
0.732(18.6)
0.692(17.6)
1.13(28.8)
1.11(28.2)
METAL HEAT SINK
0.46(11.7)
0.41(10.5)
EXOPY CASE
0.78(19.8)MIN
MECHANICAL DATA
•
•
•
•
•
•
•
•
•
0.042(1.10)DIA
0.038(0.97)TYP
Case: Molded plastic body
Terminal: Plated 0.04″(1.02mm)diameter
Polarity: Polarity symbols marked on case
Mounting: Thru hole for #10 screw, 20 in,-lbs Torque Max.
Weight: 0.47 ounce, 13.4 gram
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
O
C ambient temperature unless otherwise specified
Single Phase, half wave, 60Hz, resistive or inductive load
For capacitive load derate current by 20%
SYMBOL
FBPC
25005WN
FBPC
2501WN
FBPC
2502WN
FBPC
2504WN
FBPC
2506WN
FBPC
2508WN
FBPC
2510WN
UNIT
Volts
Volts
Volts
Amps
Amps
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Output
Current, at T
C
= 50℃ (Note 1,2)
Peak Forward Surge Current
8.3mS single half sine wave superimposed on
rated load (JEDEC method)
Rating for Fusing (t<8.3mS)
Maximum Instantaneous Forward Voltage Drop
per Bridge element at 12.5 A
Maximum DC Reverse Current at Rated
DC Blocking Voltage per element
T
A
= 25
℃
T
A
= 100
℃
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
I
2
t
V
F
I
R
T
rr
V
ISO
R
θJc
T
J
T
STG
50
35
50
100
70
100
200
140
200
400
280
400
25
300
373
600
420
600
800
560
800
1000
700
1000
A
2
s
1.3
Volts
µA
mA
250
500
NS
V
AC
O
1.2
10
1.0
150
2500
2.0
(-65 to +150)
(-65 to +150)
Maximum DC Reverse recovery time(Note3)
Isolation Voltage from case to lead
Typical Thermal Resistance (Note 1,2 )
Operating Temperature Rang
Storage Temperature Rang
C/W
O
O
C
C
Notes:
1.
2.
3.
Unit mounted on 5” x 6” x 4.9” (12.8cm x15.2cm x 12.4cm) AL finned Plate
Bolt down on heat-sink with silicon thermal compound between bridge and mounting surface for maximum beat transfer efficiency with
#10
screw
Reverse recovery test conditions: I
F
=0.5A,I
R
=1.0A,I
RR
=0.25A
1
