SCP6EP4-GL-XN-57 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Optical fiber> SCP6EP4-GL-XN-57

SCP6EP4-GL-XN-57: DescriptionTransceiver, 1565nm Min, 1578nm Max, 1250Mbps(Tx), 1250Mbps(Rx), LC Connector, Surface Mount; CategoryWireless rf/communication Optical fiber; File Size562KB，21 Pages; ManufacturerSUMITOMO; Websitehttps://global-sei.com/

Download Datasheet Parametric View All

SCP6EP4-GL-XN-57 Overview

Transceiver, 1565nm Min, 1578nm Max, 1250Mbps(Tx), 1250Mbps(Rx), LC Connector, Surface Mount

SCP6EP4-GL-XN-57 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	IT CAN ALSO BE OPERATED AT 1260NM TO 1620NM
body width	13.4 mm
body height	8.5 mm
Body length or diameter	56.5 mm
Connection Type	LC CONNECTOR
Data rate (receive)	1250 Mbps
Data rate (send)	1250 Mbps
Emitter/Detector Type	LASER
Fiber optic equipment types	TRANSCEIVER
Installation features	SURFACE MOUNT
Maximum operating wavelength	1578 nm
Minimum operating wavelength	1565 nm
Nominal operating wavelength	1570 nm
Nominal optical power output	1.995 mW
Maximum supply voltage	3.465 V
Minimum supply voltage	3.135 V
Nominal supply voltage	3.3 V
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

Specification : TS-S03D159C

March, 2005

Technical Specification

for

Small Form Factor Pluggable (SFP)

SCP69P4-GL-#N-xx

(No Diagnostic Monitoring)

SCP6EP4-GL-#N-xx

(Diagnostic Monitoring with External Calibration)

155.52M bp s

Short H aul

Interm edia te R each

Single 5.0 V

1.3 µ m

W / D iagnostic M onitor

622.08M bps

Long H a ul

Long R each

Single 3.3 V

1.55 µ m

W /O D iagnos tic M onitor

Up to 1.25Gbps

Multi Rate

other ________ ____

other

Link Budget 32dB

________ ____

CWDM (APD)

________ ____

Applicable Part Numbers :

SCP69P4-GL-AN-xx, SCP69P4-GL-BN-xx, SCP69P4-GL-CN-xx, SCP69P4-GL-XN-xx, SCP69P4-GL-YN-xx, SCP69P4-GL-ZN-xx

SCP6EP4-GL-AN-xx, SCP6EP4-GL-BN-xx, SCP6EP4-GL-CN-xx, SCP6EP4-GL-XN-xx, SCP6EP4-GL-YN-xx, SCP6EP4-GL-ZN-xx

xx:Wavelength

27: 1270nm, 29: 1290nm, 31: 1310nm, 33, 1330nm, 35, 1350nm, 37, 1370nm, 39, 1390nm, 41, 1410nm, 43, 1430nm

45: 1450nm, 47: 1470nm, 49: 1490nm, 51, 1510nm, 53, 1530nm, 55, 1550nm, 57, 1570nm, 59, 1590nm, 61, 1610nm

Sumitomo Electric reserves the right to make changes in this specification without prior notice.

Sumitomo Electric Industries, Ltd. and ExceLight Communications, Inc., have been granted license to

the following patents under a license agreement with Finisar Corporation: US 5,019,769, US 6,439,918 B1

#Safety Precaution

This specification uses various picture symbols to prevent possible injury to operator or other

persons or damage to properties for appropriate use of the product. The symbols and definitions are as shown below. Be sure to be familiar

with these symbols before reading this specification.

Symbols

Warning

Caution

Wrong operation without following this instruction may lead to human death or serious injury.

Wrong operation without following this instruction may lead to human injury or property damage.

indicates prohibition of actions. Action details are explained thereafter.

indicates compulsory actions or instructions. Action details are explained thereafter.

Example of picture symbols

(SCP69P4 / 6EP4-GL)

- 1 / 21 -
