MASTER INSTRUMENT CORPORATION
SINGLE-PHASE BRIDGE RECTIFIER
W005L THRU W10L
FEATURES
l
Low cost
l
This series is UL recognized under component
index,file number E127707
l
High forward surge current capability
l
Ideal for printed circuit board
l
High temperature soldering guaranteed:
260
o
C/10 second, 0.375”(9.5mm) lead length
at 5 lbs. (2.3kg) tension.
MECHANICAL DATA
l
Case: Molded plastic body
l
Terminal: Lead solderable per MIL-STD-202E
method 208C.
l
Polarity: Polarity symbols molded on case
l
Mounting position: Any
l
Weight:0.05ounce,1.42grams
VOLTAGE RANGE
CURRENT
50 to 1000 Volts
1.5 Amperes
.366(9.3)
.350(8.9)
.290(7.4)
.270(6.9)
1.1
(27.9)
MIN
1.0
(25.4)
MIN
POS
LEAD
~
+
.032(0.8)DIA
.028(0.7)TYP
-
~
.220(5.6)
.180(4.6)
.220(5.6)
.180(4.6)
Dimensions in inches and (millimeters)
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load derate current by 20%.
SYMBOLS W005L
Maximum Repetitive Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward
Rectified Output Current, at
T
A
=25℃
V
RRM
V
RMS
V
DC
I
(AV)
I
FSM
V
F
I
R
C
J
R
θ
JA
T
J
T
STG
50
35
50
W01L
100
70
100
W02L
200
140
200
W04L
400
280
400
1.5
50
1.0
10
0.5
15
40
-55 to +150
-55 to +150
W06L
600
420
600
W08L
800
560
800
W10L
1000
700
1000
UNITS
Volts
Volts
Volts
Amps
Amps
Volts
µAmps
mAmps
P
F
℃/W
℃
℃
Peak Forward Surge Current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Maximum Instantaneous Forward Voltage at 1.0A
Maximum DC Reverse Current at rated
DC blocking voltage
Typical Junction Capacitance(Note1)
Typical Thermal Resistance(Note2)
Operating Temperature Range
Storage Temperature Range
T
A
=25℃
T
A
=100℃
NOTES:
1.
Measured at 1.0MHz and applied reverse voltage of 4.0 volts.
2.
Unit mounted on P.C. board with 0.22”×0.22”(5.5×5.5mm)copper pads,0.375”(9.5mm)lead length.
E-mail:
sales@cnmic.com
Web Site: www.cnmic.com
1/2
