W02M Overview

GENESIC SEMICONDUCTOR - W02M - BRIDGE RECTIFIER; 1PH; 1.5A; 200V; DOB

Preview

Download Datasheet

View All

MASTER INSTRUMENT CORPORATION

SINGLE-PHASE BRIDGE RECTIFIER

W005M THRU W10M

FEATURES

Low cost

This series is UL recognized under component

index,file number E127707

High forward surge current capability

Ideal for printed circuit board

High temperature soldering guaranteed:

260

C/10 second, 0.375”(9.5mm) lead length

at 5 lbs. (2.3kg) tension.

MECHANICAL DATA

Case: Molded plastic body

Terminal: Lead solderable per MIL-STD-202E

method 208C.

Polarity: Polarity symbols molded on case

Mounting position: Any

Weight:0.042ounce,1.2grams

VOLTAGE RANGE

CURRENT

50 to 1000 Volts

1.5 Amperes

.366(9.3)

.350(8.9)

.220(5.6)

.200(5.1)

1.1

(27.9)

MIN

1.0

(25.4)

MIN

POS

LEAD

.032(0.8)DIA

.028(0.7)TYP

.220(5.6)

.180(4.6)

.220(5.6)

.180(4.6)

Dimensions in inches and (millimeters)

MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS

Ratings at 25

C ambient temperature unless otherwise specified.

Single phase, half wave, 60Hz, resistive or inductive load.

For capacitive load derate current by 20%.

SYMBOLS W005M

Maximum Repetitive Peak Reverse Voltage

Maximum RMS Voltage

Maximum DC Blocking Voltage

Maximum Average Forward

Rectified Output Current, at

=25℃

RRM

RMS

(AV)

FSM

STG

W01M

100

W02M

200

140

200

W04M

400

280

400

1.5

1.0

0.5

-55 to +125

-55 to +150

W06M

600

420

600

W08M

800

560

800

W10M

1000

700

1000

UNITS

Volts

Amps

Volts

µAmps

mAmps

℃/W

℃

Peak Forward Surge Current 8.3ms single half sine-wave

superimposed on rated load (JEDEC Method)

Maximum Instantaneous Forward Voltage at 1.0A

Maximum DC Reverse Current at rated

DC blocking voltage

Typical Junction Capacitance(Note1)

Typical Thermal Resistance(Note2)

Operating Temperature Range

Storage Temperature Range

=25℃

=100℃

NOTES:

Measured at 1.0MHz and applied reverse voltage of 4.0 volts.

Unit mounted on P.C. board with 0.22”×0.22”(5.5×5.5mm)copper pads,0.375”(9.5mm)lead length.

E-mail:

sales@cnmic.com

Web Site: www.cnmic.com

1/2
