DATA SHEET
MOS Integrated Circuit
µ
PD78P322
16/8-BIT SINGLE-CHIP MICROCONTROLLER
The
µ
PD78P322 is a version provided by replacing the
µ
PD75322's internal mask ROM with one-time PROM
or EPROM.
Because the one-time PROM version is programmable only once by users, it is ideally suited for small-scale
production of many different products, and rapid development and time-to-market of application sets.
The EPROM version is reprogrammable, and suited for the evaluation of systems.
The
µ
PD78P322K, which is the EPROM version, does not maintain planned reliability when
used in mass-produced products. Please use only experimentally or for evaluating functions
during trial manufacture.
Functions are described in detail in the following user's manual. Be sure to read it for designing.
µ
PD78322 User's Manual: IEU-1248
FEATURES
•
µ
PD78322 compatible
• For mass-production, the
µ
PD78P322 can be replaced with the
µ
PD78322 which incorporates mask
ROM
•
Internal PROM: 16,384
×
8 bits
• Programmable once only (one-time PROM version without window)
• Erasable with ultraviolet rays and electrically programmable (EPROM version with window)
•
•
PROM programming characteristics:
µ
PD27C256A compatible
The
µ
PD78P328 is a QTOP
TM
microcontroller
Remark
QTOP microcontroller is a general term for microcontrollers which incorporate one-time PROM, and
are totally supported by NEC's programming service (from programming to marking, screening, and
verification).
ORDERING INFORMATION
Part Number
Package
80-pin plastic QFP (14
×
20 mm)
74-pin plastic QFP (20
×
20 mm)
68-pin plastic QFJ (950
×
950 mils)
80-pin ceramic WQFN
68-pin ceramic WQFN
74-pin ceramic WQFN
Internal ROM
One-time PROM
One-time PROM
One-time PROM
EPROM
EPROM
EPROM
Quality Grade
Standard
Standard
Standard
Not applicable
Standard
Standard
µ
PD78P322GF-3B9
µ
PD78P322GJ-5BJ
µ
PD78P322L
µ
PD78P322K
µ
PD78P322KC
µ
PD78P322KD
Please refer to "Quality grade on NEC Semiconductor Devices" (Document number IEI-1209) published by NEC Corporation to know the
specification of quality grade on the devices and its recommended applications.
Functions common to the one-time PROM and EPROM versions are referred to as PROM functions throughout this document.
The information in this document is subject to change without notice.
Document No. U10435EJ5V0DS00 (5th edition)
(Previous No. IC-2485)
Date Published December 1995 P
Printed in Japan
The mark
*
shows revised points.
©
©
1991
1994
