GDB-1.25A Overview

GDB-1.25A,

GDB-1.25A Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Reach Compliance Code	compliant
Fusing characteristics	FAST
body height	20 mm
Body length or diameter	5.2 mm
Circuit protection type	ELECTRIC FUSE
Joule integral nominal
Manufacturer's serial number	GDB
Installation features	INLINE/HOLDER
physical size	5.2mm x 20mm
Rated breaking capacity	35 A
Rated current	1.25 A
Rated voltage (AC)	250 V
Guideline	BSI; IMQ; SEMKO; UL; VDE
surface mount	NO
Terminal surface	Nickel (Ni)
Terminal shape	END CAP
Base Number Matches	1

Preview

Download Datasheet

View All

5mm x 20mm Fuses

GDB Series, Fast Acting, Glass Tube

Description

• Fast acting, low breaking capacity

• 5mm x 20mm physical size

• Glass tube, nickel-plated brass endcap construction

• Optional axial leads are .032" x 1.5" copper tinned

• Optional sleeve is flexible flouropolymer

(U.L. flammability rating VW-1).

• Designed to IEC 60127-2-1

ELECTRICAL CHARACTERISTICS

1.5 In 2.1 In

2.75 In

4 In

10 In

In

min

max

min

max

min

max

32mA-100mA 60 min 30 min 10 ms 500 ms 3 ms 100 ms 20 ms

125mA-6.3A 60 min 30 min 50 ms 2 sec 10 ms 300 ms 20 ms

Dimensions

Drawing Not to Scale

1.1 In:

∆t

less than or equal to 70°C, 125ma-3A

1.0 In:

∆t

less than or equal to 70°C, 4A

Ordering

• Specify product code, option code and packaging code

Approvals

• UL Recognized, Guide JDYX2, File E75865, 32mA-6.3A

• Semko Approval 32mA-400mA and 800mA-6.3A

• VDE Approval 160mA-6.3A

• BSI Approval 160mA-6.3A

• IMQ Approval 160mA-6.3A

SPECIFICATIONS

Product Code

GDB-32mA

GDB-40mA

GDB-50mA

GDB-63mA

GDB-80mA

GDB-100mA

GDB-125mA

GDB-160mA

GDB-200mA

GDB-250mA

GDB-315mA

GDB-400mA

GDB-500mA

GDB-630mA

GDB-800mA

GDB-1A

GDB-1.25A

GDB-1.6A

GDB-2A

GDB-2.5A

GDB-3.15A

GDB-4A

GDB-5A

GDB-6.3A

Voltage

Rating

AC

250V

Interrupting Rating

at Rated Voltage (50Hz)

AC/DC

35A

Typical DC

Cold Resistance

(ohms)*

41.5

25.5

17.5

12.9

5.2

3.9

2.9

9.2

7.0

4.5

3.2

1.9

0.27

0.21

0.15

0.13

0.098

0.068

0.044

0.035

0.026

0.022

0.015

0.010

Typical

Melting I

2

t (A

2

Sec)

AC†

0.000047

0.00011

0.00020

0.00057

0.0012

0.003

0.005

0.008

0.016

0.28

0.58

0.18

0.35

0.67

0.60

0.84

1.6

4.2

6.1

13

22

42

69

Maximum

Voltage

Drop (mV)‡

3200

2500

2400

2000

1200

1100

1000

2000

1700

1400

1300

1100

220

190

200

190

150

130

120

* DC Cold Resistance (Measured at <10% of rated current)

† Typical Melting I

2

t (I

2

t was measured at listed interrupting rating and rated voltage)

‡ Maximum Voltage Drop (Voltage drop was measured at 20°C ambient temperature at rated current)
