VDS1142 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > VDS1142

Preview

VDS1142: DescriptionTR Limiter; File Size325KB，1 Pages; ManufacturerCPI; Websitehttp://www.cpii.com/

Download Datasheet View All

VDS1142 Overview

TR Limiter

Preview

Download Datasheet

View All

Receiver Protectors

VDS1142 TR Limiter

Features:

Frequency: 2.7 to 2.95 GHz

Overload Power: 150 kW peak

Normal Operating Power: 15 kW peak

Pulsewidth: 3.0

mSec

max

Duty Cycle: .002 max

Insertion Loss: 0.4 dB max

VSWR: 1.4:1 max

Flat Leakage: 50 mW max

Spike Leakage: 3.0 W max

Recovery Time: 4.0 uS max

WG: WR284

Operating Temperature: -55 to +85

Description:

High power S-Band TR Limiter

150 Sohier Road

Beverly, Massachusetts 01915

Phone: 978-922-6000 Fax: 978-922-2736

E-Mail: marketing@bmd.cpii.com

Internet: www.cpii.com/bmd

Beverly Microwave Division
