F-208-1
TFSD–15–30–H–05.00–D–NDX
TFSD–10–28–H–05.00–T–NUS
HEADER CABLE ASSEMBLY
TFSD SERIES
Mates with:
SFM, SFC
TFSD
NO. POSITIONS
PER ROW
WIRE
GAUGE
PLATING
OPTION
ASSEMBLED
LENGTH
END
OPTION
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?TFSD
Insulator Material:
Black LCP
Contact Material:
BeCu
Plating:
Au over 50µ" (1,27µm) Ni
Operating Temp Range:
-55°C to +80°C
Wire:
28 or 30 AWG
RoHS Compliant:
Yes
–05, –07, –10, –15,
–20, –25, –30
(Call Samtec for other sizes)
No. of Positions x
(1,27) .050
+ (2,54) .100
(3,94)
.155
01
02
–30
= 30 AWG
–H
= 30µ"
(0,76µm)
Gold on
contact
–“XX.XX”
= Assembled
Length in
Inches
(76,20mm)
03.00" min. for
–S end option
(82,60mm)
03.25" min. for
–D end option
–S
= Single
Ended
= Double
Ended
(End
No. 2
notch
options
required)
= Transfered
End
Terminal
on End 1
Socket
on End 2
(End 2
notch
options
required)
–28
= 28 AWG
–D
(6,10)
.240
(1,27)
.050
(4,57)
.180
Available
on –D End
Option
only.
Applies to
End No. 2
housing
(End No. 1
is always
Notch Up).
–NUS
= Notch up,
straight
APPLICATION
SPECIFIC OPTION
• Locking feature
available for mating to
the TFML Series
• Color coded cable
available
Call Samtec.
Notch
End 1
(14,26)
.562
(6,05)
.238
Notch
End 1
Notch
End 1
Notch
End 1
–T
–NDS
= Notch
down,
straight
Assembled
Length
± (3,18)
.125
–NUX
= Notch up,
crossed
–S
Notch
End 2
Notch
End 2
–NDX
= Notch
down,
crossed
–NDX
–NUS
–NDS
–NUX
Note:
Some lengths, styles
and options are non-standard,
non-returnable.
TYPE
POSITIONS
PER ROW
D
S
T1M44
CONTACT
WIRE
GAUGE
01
PLATING
TSDF
= Housing
–05, –07, –10, –15,
–20, –25, –30
(Call Samtec for other sizes)
No. of Positions x
(1,27) .050
+ (2,54) .100
02
–R
= Full Reel
(35,000 Contacts per Reel)
–2830
= 28 to 30 AWG
–H
= 30µ" (0,76µm)
Gold on contact
–L
= Loose
(0,46) .018 DIA
(3,94)
.155
(4,57)
.180
(6,10)
.240
(1,27)
.050
01
(14,26)
.562
(6,05)
.238
(3,81) .150
WWW.SAMTEC.COM
