50W Solid State BUCs
CPI Solid Inside and Out
Ku - B a n d
Model B3UO
50 watt Ku-band
Solid State Block
Upconverters —
Environmentally sealed
compact design for
outdoor operation
CPI-Built RF Brick Inside
Global Applications
Ku-Band
With CPI-built RF brick inside and plenty of
thermal margin, this SSPA is rock-solid, highly
efficient and easy to maintain.
High LInearity
Excellent AM/PM, phase noise and spectral
regrowth performance.
Simple to Operate
Perfect for Satcom on the Move, Micro
Flyaway Systems, VSATs, and antenna-
mount applications. Meets International
Safety Standard EN-60950, Electromagnetic
Compatibility 89/336/EEC and Harmonic
Standard EN-61000-3-2 to satisfy
worldwide requirements.
Worldwide Support
50W Solid State BUCs
User-friendly microprocessor-controlled
logic with both integrated serial (RS-232
and RS-422/485) and Ethernet computer
interfaces. Also contains digitally controlled
attenuator.
Extended Band Operation
Backed by over three decades of satellite
communications experience, and CPI’s
worldwide 24-hour customer support network
that includes sixteen regional factory
service centers.
Provides 45 watts of P1dB output power at
the flange over the entire 13.75 to 14.50 GHz
frequency range.
811 Hansen Way
P.O. Box 51625, Palo Alto, CA 94303
tel:
+1 (650) 846-3803
fax:
+1 (650) 424-1744
e-mail:
satcommarketing@satcom.cpii.com
www.cpii.com/satcom
Ku -B an d
SPECIFICATIONS, 50 W Ku-Band Outdoor
Solid State BUC
(Model B3UO)
Electrical
Monitor and Control
13.75 to 14.50 GHz
950 to 1700 MHz
50W (47.0 dBm) Psat
45W (46.5 dBm) P1dB
12,800 MHz or 13,050 MHz (select either)
standard
70 dB min. (higher gain options available)
±1.0 dB over oper. temp. range
±0.25 dB
±0.04 dB/MHz max.
±0.85 dB pk-pk max.
±1.25 dB
17 dB
1.5:1 max. (50 ohms)
1.3:1 max.
Cooling
Shock and Vibration
Relative Humidity
Altitude
Remote Control
Transmit ON/OFF
Fault Reset
Attenuator Setting
OPTIONS:
• 14.0 - 14.5 GHz
operation
• Front Panel
Display
Frequency
L-Band Input
Output Power
Local Oscillator Frequency
Internal 10 MHz Reference
Small Signal Gain
Gain Stability
Over temp., constant drive
Over 24 hours, fixed temp.
Gain Slope
Small Signal Gain Variation
Across any 80 MHz band
Across the full band
Gain Adjustment Range
Input VSWR
Output VSWR
Load VSWR
Continuous operation
Full spec compliance
Residual AM, max.
Phase Noise, max.
100 Hz
1 kHz
10 kHz
100 kHz
1 MHz
AM/PM Conversion
Harmonic Output
Spurious Response at P1dB
Intermodulation Distortion
Computer/Network Interface RS-232C, 422/485 and Ethernet
Remote Status
Transmit ON/OFF, Summary Fault
Temperature, Fault Identification
RF Inhibit (ON/OFF), Lock Detect
Environmental
Ambient Temperature
-40°C to +60°C operating,
solar loading immune;
-50°C to +85°C non-operating
100% condensing
12,000 ft. with standard adiabatic
derating of 2°C/1000 ft., operating;
50,000 ft., non-operating
Integral forced air
20 g peak, 11 msec, 2 sine;
2.1 g
rms
, 5 to 500 Hz.
Mechanical
2.0:1
1.5:1
-80 dBc > 100 kHz from carrier
L-Band Input connection
-63 dBc/Hz
-73 dBc/Hz
-83 dBc/Hz
-93 dBc/Hz
-103 dBc/Hz
2.5°/dB max. for a single-carrier at
2.5 dB backoff from P1dB
-60 dBc max. at P1dB
-60
dBc max. in band
-25 dBc max. with two equal carriers and
5 MHz apart at 3.0 dB total backoff
from P1dB
0.03 ns/MHz linear max.
0.003 ns/MHz
2
parabolic max.
1.0 ns pk-pk ripple max.
Single phase, 100-250 VAC ±10%
47-63 Hz
428 VA typ.
0.95 min.
M&C Connection
Dimensions
Weight
RF Output Connection
WR-75 waveguide flange,
grooved with UNC 2B 6-32
threaded holes
Type N female
12 Pin Circular (LF10WBR-12S)
6 x 6 x 16 in.
(142 x 142 x 406 mm)
25 lbs (11.4 kg) typ.
Group Delay
(in any 80 MHz band)
Primary Power
Power Consumption
Power Factor
Certificate Number: 30515
For more detailed information, please refer to the corresponding CPI Technical Description.
Note:
Specifications may change without notice as a result of additional data or product refinement.
Please contact CPI before using this information for system design.
MKT 193, ISSUE 17
