52189 Product Details
Ring and Spade Tongue Terminals
Always EU RoHS/ELV Compliant
(
Statement of
Compliance
)
Quick Links
Check Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
Product Highlights:
Terminal Shape = Ring Tongue
Receptacle Style = Straight
Body Style = PIDG
Barrel Type = Closed Barrel
Wire/Cable Type = Regular Wire
View all Features
52189
(MS25036-144)
TE Internal Number: 52189
Active
View 3D PDF
Add to My Part List
Request Sample
Find Similar Products
Buy Product
Documentation & Additional Information
Product Drawings:
TERMINAL, RECTANGULAR TONGUE, PIDG WIRE SIZE: 26-24 AWG
(PDF, English)
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
Pre-Insulated Diamond Grip (PIDG) Terminals, Splices...
(PDF, English)
Instruction Sheets:
None Available
CAD Files:
(CAD
Format & Compression Information)
2D Drawing
(DXF, Version B)
3D Model
(IGES, Version B)
3D Model
(STEP, Version B)
Additional Information:
Product Line Information
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
Terminal Shape
= Ring Tongue
Receptacle Style
= Straight
Body Style
= PIDG
Barrel Type
= Closed Barrel
Wire/Cable Type
= Regular Wire
Insulation
= Yes
Insulation Support
= Insulation Support
Insulation Diameter (mm [in])
= 2.67 [.105] Max.
Stud Diameter (mm [in])
= 2.84 [0.112]
Stud Size = 4
Shape
= RING-041
Heavy Duty
= No
Material
= Copper
Finish
= Tin
Color = Yellow
Insulation Material = Nylon
Electrical Characteristics:
Voltage (VAC) = 300
Packaging Features:
Packaging Method
= Loose Piece
Other:
Brand = AMP
Body Features:
Wire Range (mm [AWG])
= 0.12-0.24² [26-24]
Tongue Material Thickness (mm [in]) = 0.74 [0.029]
Contact Features:
Class = 1 & 2
Industry Standards:
Government/Industry Qualification = Yes
Government/Industry Part Number = MS25036-144
RoHS/ELV Compliance
= RoHS compliant, ELV compliant
Lead Free Solder Processes
= Not relevant for lead free process
RoHS/ELV Compliance History = Always was RoHS compliant
Termination Features:
Wire/Cable Size (CMA) = 238 – 475
