Product Specification
Single Mode 1300 nm
1.0625 Gbit/s Fibre Channel 1.3 Gigabit Ethernet 1x9 Transceiver
V23826-K15-Cxx
V23826-K15-Cxxx
PRODUCT FEATURES
• Compliant with Fibre Channel and Gigabit
Ethernet standard
• Meets mezzanine standard height of
9.8 mm
• Compact integrated transceiver unit with
– MQW laser diode transmitter
– InGaAs PIN photodiode receiver
– Duplex SC receptacle
• Class 1 FDA and IEC laser safety
compliant
• FDA Accession No. 9520890-19
• Single power supply (5 V or 3.3 V)
• Signal detect indicator (PECL and TTL
version)
• PECL differential inputs and outputs
• Process plug included
• Input Signal Monitor (DC/DC-Version)
• Wave solderable and washable with
process plug inserted
• For distances of up to 10 km on single
mode fiber, and up to 550 m on multimode
fiber (use offset jumper as specified in
IEEE 802.3)
File: 1167
APPLICATIONS
• 1.25 Gbit/s 1000 Base-LX10 Ethernet
• 1.063 Gbit/s 100-SM-LC-L Fibre Channel
For
PRODUCT SELECTION
see next page.
© Finisar Corporation August 27, 2004 Rev. B
Page 1
V23826-K15-Cxx, V23826-K15-Cxxx Product Specification – August 2004
PRODUCT SELECTION
Part Number
V23826-K15-C313
V23826-K15-C53
V23826-K15-C353
V23826-K15-C63
1)
V23826-K15-C363
1)
V23826-K15-C73
V23826-K15-C373
Add Suffix to P/N
-C3
-D3
Notes:
1) Standard version.
Voltage
3.3 V
5V
3.3 V
5V
3.3 V
5V
3.3 V
Signal
Detect
PECL
TTL
PECL
PECL
Input
AC
AC
DC
AC
Output
DC
AC
DC
AC
Shield Options
Metallized cover, forward springs
Metallized cover, backward springs
© Finisar Corporation August 27, 2004 Rev. B
Page 2
V23826-K15-Cxx, V23826-K15-Cxxx Product Specification – August 2004
Pin Configuration
Tx
Top view
Rx
1 2 3 4 5 6 7 8 9
File: 1340
Figure 1
Pin Description
Pin
No.
1
2
3
4
Symbol
Level/Logic
Power Supply
PECL Output
PECL Output
active high
(TTL C53/353)
Power Supply
PECL Input
Power Supply
Mech. Support
Function
Rx Ground
Description
Negative power supply,
normally ground
Inverted receiver output data
Rx Signal
Detect
Rx 3.3 V/5 V
Tx 3.3 V/5 V
Tx Input Data
Tx Ground
Stud Pin
Inverted transmitter input data
Transmitter input data
Negative power supply,
normally ground
Not connected
High level on this output shows
there is an optical signal
Positive power supply, 3.3 V/5 V
V
EE
Rx
RD+
RD–
SD
Rx Output Data Receiver output data
5
6
7
8
9
S1/
S2
V
CC
Rx
V
CC
Tx
TD–
TD+
V
EE
Tx
© Finisar Corporation August 27, 2004 Rev. B
Page 3
V23826-K15-Cxx, V23826-K15-Cxxx Product Specification – August 2004
Description
The Finisar single mode transceiver is based on and compliant to the Physical Medium
Depend (PMD) sublayer and baseband medium, type 1000 Base-LX (long wavelength)
as specified in IEEE 802.3 and Fibre Channel FC-PI Rev. 13 100-SM-LC-L.
The appropriate fiber optic cable is 9
µm
(mode field diameter) single mode fiber (up to
10 km) with Duplex SC connector.
The Finisar single mode transceiver is a single unit comprised of a transmitter, a
receiver, and an SC receptacle. This design frees the customer from many alignment
and PC board layout concerns. The module is designed for low cost LAN, WAN and
Gigabit Ethernet applications. It can be used as the network end device interface in
mainframes, workstations, servers, and storage devices, and in a broad range of
network devices such as bridges, routers, intelligent hubs, and local and wide area
switches.
This transceiver operates at 1.0625 and 1.3 Gbit/s from a single power supply (+5 V or
3.3 V). The full differential data inputs and outputs are PECL compatible.
© Finisar Corporation August 27, 2004 Rev. B
Page 4
V23826-K15-Cxx, V23826-K15-Cxxx Product Specification – August 2004
Functional Description
This transceiver is designed to transmit serial data via single mode or multimode cable.
Signal Monitor and
Automatic Shut-Down
LEN
TD−
TD+
Laser ISM *
Driver
Power
Control
Monitor
RD−
RD+
SD
Receiver
Laser
Coupling Unit
e/o
Laser
o/e
Rx
Coupling Unit
o/e
Single
Mode
Fiber
* DC/DC Version only
File: 1360
Figure 2
Functional Diagram
The receiver component converts the optical serial data into PECL compatible electrical
data (RD+ and RD–). The Signal Detect (SD, active high) shows whether an optical
signal is present.
The transmitter converts electrical PECL compatible serial data (TD+ and TD–) into
optical serial data.
The following versions are available:
1 AC/DC Transceiver: Tx is AC coupled. Differential 100
Ω
load. Rx has standard PECL
output and is DC coupled.
2 AC/AC TTL Transceiver: Tx and Rx are AC coupled. Tx has differential 100
Ω
load.
Signal Detect is TTL compatible.
3 DC/DC Transceiver: Standard PECL inputs and outputs Tx and Rx are DC coupled.
This version contains an Input Signal Monitor (ISM) which switches off the transceiver
if a continuous low level is applied at Data Input.
4 AC/AC PECL Transceiver: Tx and Rx are AC coupled. Tx has differential 100
Ω
load.
Signal Detect is PECL compatible.
© Finisar Corporation August 27, 2004 Rev. B
Page 5
