SMT POWER INDUCTORS
Unshielded Drum Core - PB2020 Series
Height:
10.2mm Max
Footprint:
23.9mm x 20.8mm Max
Current Rating:
up to 30A
Inductance Range:
0.65µH to 29µH
Electrical Specifications @ 25°C — Operating Temperature -40°C to +130°C
Part
6,7
Number
PB2020.681
PB2020.102
PB2020.222
PB2020.332
PB2020.472
PB2020.682
PB2020.103
PB2020.153
PB2020.223
PB2020.333
Inductance
2
@ Irated
(µH MIN)
0.65
0.85
1.83
3.00
4.00
5.78
8.30
13.00
18.70
29.00
Irated
3
(A
DC
)
30.0
23.7
21.8
18.3
16.8
13.6
12.6
9.7
8.1
6.5
DCR
(mΩ)
(TYP)
1.62
1.98
2.34
3.33
3.96
6.03
7.02
11.70
17.10
26.10
(MAX)
1.80
2.20
2.60
3.70
4.40
6.70
7.80
13.00
19.00
29.00
Inductance
@ 0 A
DC
(µH ±15%)
0.65
0.85
1.83
3.00
4.00
5.78
8.30
13.00
18.70
29.00
Saturation Current
4
@ 25°C
(A
DC
)
70
55
40
35
28
25
20
18
13
10
Heating
5
Current
(A
DC
)
30.0
23.7
21.8
18.3
16.8
13.6
12.6
9.7
8.1
6.5
NOTES:
1. The temperature of the component (ambient plus temperature rise) must be within
the specified operating temperature range.
2. Inductance at Irated is typical inductance value for component taken at rated current.
3. The rated current listed is the lower of saturation current @ 25°C or heating current.
4. The saturation current, Isat, is the current at which the component inductance drops
by 10% (typical) at an ambient temperature of 25°C. This current is determined by
placing the component in the specified ambient environment and applying a short
duration pulse current (to eliminate self-heating effects) to the component.
5. The heating current, I
DC
, is the DC current required to raise the component
temperature by approximately 40°C. The heating current is determined by mounting
the component on a typical PCB and applying current for 30 minutes.
6. Optional Tape & Reel packaging can be ordered by adding a "T" suffix to the
part number (i.e. PB2020.102 becomes PB2020.102T). Pulse complies to industry
standard tape and reel specification EIA481.
7. To order RoHS compliant part, add the suffix “NL” to the part number
(i.e. PB2020.102 becomes PB2020.102NL and PB2020.102T becomes
PB2020.102NLT).
Mechanical
.940
23,87
MAX
.820
20,83
MAX
.400
10,16
MAX
Schematic
1
2
6
SUGGESTED PAD LAYOUT
.960
24,39
.680
17,27
INDUCTANCE ( µH )
Date Code
Country of Origin
PB2020.XXX
INDUCTANCE 0.65 µH TO 4.0 µH
.472
.332
.222
.102
.681
1
4
7
10 13 16 19
22 25 28
31 34 37 40 43
46 49 52
.530
13,46
5
4
3
2
1
0
Weight
. . . . . . . .9.5 grams
Tape & Reel
. . . . . .100/reel
Tray
. . . . . . . . . . . . .20/tray
.420
10,67
Dimensions:
Inches
mm
Unless otherwise specified, all tolerances are ± .010
0,25
CURRENT ( A
DC
)
INDUCTANCE 5.78 µH TO
29.0
µH
.333
.223
.153
.103
.682
1
4
7
10
13
16
19
22
25
28
31
34
37
40
35
.950
24,13
1.591
40,41
1.732
± .012
44,00
± 0,30
INDUCTANCE ( µH )
30
25
20
15
10
5
0
TAPE & REEL LAYOUT
.820
20,83
1.260
32,00
USER DIRECTION OF FEED
CURRENT ( A
DC
)
USA 858 674 8100
•
Germany 49 7032 7806 0
•
Singapore 65 6287 8998
•
Shanghai
86 21 54643211 / 2
•
China 86 755 33966678
•
Taiwan 886 3 4641811
www.pulseeng.com
26
SPM2007 (7/07)
