BAS21W
Elektronische Bauelemente
FEATURES
Fast Switching Speed
Surface Mount Package Ideally Suited for
Automatic Insertion
For General Purpose Switching Applications
High Conductance
1
3
1
3
Surface Mount Switching Diode
RoHS Compliant Product
A suffix of "-C" specifies halogen & lead-free
A
L
B S
Top View
2
V
G
C
D
H
K
J
3
CATHODE
1
ANODE
2
MAXIMUM RATINGS
Parameter
Continuous Reverse Voltage
Average Rectified Output Current
Power Dissipation
Thermal Resistance, Junction to Ambient
Junction and Storage Temperature
Symbol
VR
Io
PD
R
θ
JA
TJ, Tstg
Value
200
200
200
625
±55 to +150
Unit
Vdc
mA
mW
ο
C/W
ο
SOT-323(SC-70)
Dim
A
B
C
D
G
H
J
K
L
S
V
Min
1.800
1.150
0.800
0.300
1.200
0.000
0.100
0.350
0.590
2.000
0.280
Max
2.200
1.350
1.000
0.400
1.400
0.100
0.250
0.500
0.720
2.400
0.420
C
DEVICE MARKING
BAS21W = KT3
ELECTRICAL CHARACTERISTICS
(TA = 25
o
C unless otherwise noted)
Characteristic
Reverse Voltage Leakage Current
(VR = 200 V)
Reverse Breakdown Voltage
(IR = 100
µAdc)
Forward Voltage
(IF = 100 mAdc)
(IF = 200 mAdc)
Diode Capacitance
(VR = 0, f = 1.0 MHz)
Reverse Recovery Time
(IF = IR = 30 mAdc, Irr = 0.1 x I
R
)
Symbol
IR
V(BR)
200
Min
Max
0.1
Unit
µAdc
Vdc
VF
CD
trr
1
1.25
5
50
V
All Dimension in mm
pF
ns
TYPICAL CHARACTERISTICS
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individual
01-Jun-2002 Rev. A
Page 1 of
1
