DTA114YE/DTA114YUA/DTA114YKA
DTA114YSA/DTA114YCA
Elektronische Bauelemente
PNP Digital Transistors (Built-in Resistors)
FEATURES
* Built-in bias resistors enable the configuration of
an inverter circuit without connecting input resistors
(see equivalent circuit).
* Only the on/off confitions need to be set for operation,
making device design easy.
* The bias resistors consis of thin-film resistors with
compete isolation to allow negative biasing of the
input. They also have the advantage of almost
completely eliminating parasitic effects.
PIN CONNENCTIONS AND MARKING
DTA114YE
DTA114YUA
DTC114EUA
SOT-323
SOT-523
Abbreviated symbol: 54
Abbreviated symbol: 54
DTA114YKA
DTA114YCA
SOT-23-3L
SOT-23
Abbreviated symbol: 54
Abbreviated symbol: 54
DTA114YSA
TO-92S
http://www.SeCoSGmbH.com
l
Any changing of specification will not be informed individua
01-Jun-2002 Rev. A
Page 1 of 2
DTA114YE/DTA114YUA/DTA114YKA
DTA114YSA/DTA114YCA
Elektronische Bauelemente
Absolute maximum ratings(Ta=25℃)
Parameter
Supply voltage
Input voltage
Output current
Power dissipation
Junction temperature
Storage temperature
Symbol
V
CC
V
IN
I
O
I
C(Max.)
P
C
Tj
Tstg
150
Limits (DTA114Y□ )
E
UA
KA
-50
-40to+6
-70
-100
200
150
-55 to+ 150
300
CA
SA
Unit
V
V
mA
mA
mW
℃
℃
PNP Digital Transistors (Built-in Resistors)
Electrical characteristics (Ta=25℃)
Parameter
Input voltage
Output voltage
Input current
Output current
DC current gain
Input resistance
Resistance ratio
Transition frequency
Symbol
V
I(off)
V
I(on)
V
O(on)
I
I
I
O(off)
G
I
R
1
R
2
/R
1
f
T
68
7
3.7
10
4.7
250
13
5.7
MHz
V
O
=-10V ,I
O
=5mA,f=100MHz
KΩ
-1.4
-0.3
-0.88
-0.5
Min.
Typ
Max.
-0.3
Unit
V
V
mA
µA
Conditions
V
CC
=-5V ,I
O
=-100µA
V
O
=-0.3V ,I
O
=-1mA
I
O
/I
I
=-5mA/-0.25mA
V
I
=-5V
V
CC
=-50V ,V
I
=0
V
O
=-5V ,I
O
=-5mA
Typical Characteristics
http://www.SeCoSGmbH.com
Any changing of specification will not be informed individua
01-Jun-2002 Rev. A
Page 2 of 2
