Module no:3024070 LabelId:3024070 Operator:Phoenix
18:57:50, Donnerstag, 28. Juni 2001
ZFK 4-TWIN
Terminal width 6.2
(IEC)
[mm ]
IEC 947-7-1
EN 50 019 **
2
rigid
solid
0.5-6
0.5-6
flexible
stranded AWG
0.5-4
0.5-4
20-10
–
I
[A]
32*
33/28*
U
[V]
800
550
* The max. load current must not be exceeded by the residual current of all connected conductors.
** Certification: KEMA Ex-96.D.4367U
KEMA
Description
Spring cage terminal block,
for mounting on
3
Color
gray
blue
Accessories
(1)
End cover
gray
D-ZFK 4-TWIN
30 24 24 5
50
Type
ZFK 4-TWIN
ZFK 4-TWIN BU
Order No.
30 24 07 0
30 25 42 2
Pcs.
Pkt.
50
50
(2)
Insulation stop sleeve,
prevents
the insulation being accidentally
clamped with smaller cross sects.
cross section
range:
0.25-0.5 mm
0.75-1 mm
(3)
Fixed bridge,
for
cross-connections in the
terminal center, divisible,
screw heads with insulation
collars
(4)
Plug-in bridge,
2
), for
cross-connections in the
terminal center, labelling on
insulated spine
(5)
Separating plate,
for
electrical separation of
neighboring bridges, can be
fitted later, no loss of pitch
(6)
Partition plate,
for optical
and electrical separation of
terminal block groups, 2 mm
thick
(7)
Test plugs,
assembled as a block of 10
(8)
Screwdriver,
for actuating
the tension spring
2
gray
black
10-pos.
ZFK 4-ISH 0,5
ZFK 4-ISH 1
FBI 10-6
30 02 88 5
30 02 89 8
I
max.
: 32 A
02 03 25 0
50
50
10
2
2-pos.
3-pos.
10-pos.
FBSTB 2-6
FBSTB 3-6
FBSTB 10-6
TS-U3K 2,5
I
max.
: 30 A
30 25 78 1
30 A
30 25 79 4
30 A
30 25 86 2
27 70 06 6
10
10
10
100
ATP-ZFK 4-TWIN
30 24 57 5
50
PS-ZFK 4
SZF 1 - 0,6 x 3,5
30 00 98 4
12 04 51 7
10
1
Page 1 / 2
Phoenix Contact Elektronischer Katalog
Module no:3024070 LabelId:3024070 Operator:Phoenix
(9)
Actuation tool,
for
actuating the tension spring
(10)
Zack marker sheet, flat,
100 or 120-section, for
labelling the outer marker
grooves
(11)
Zack strip,
10-section, for
labelling in the terminal center
and on the plug-in bridges
Technical data
Dimensions
Width / length / end cover width
Height (NS 35:7.5 / NS 35:15)
Technical data in accordance with IEC/
DIN VDE
Maximum load current / cross section
Rated surge voltage / contamination class
Surge voltage category / insulation material
group
Connection capacity
stranded with ferrule with plastic sleeve
stranded with ferrule without plastic sleeve
stranded with TWIN ferrule with plastic
sleeve
Stripping length
Internal cylindrical gage (IEC 947-1:1988)
Insulation material
Inflammability class acc. to UL 94
Temperature indices RTI / Ti
2
18:57:50, Donnerstag, 28. Juni 2001
30 02 94 0
30 02 95 3
1
1
2-pos.
3-pos.
ZFK-BW 2-6
ZFK-BW 3-6
ZBFM 6
(see
info)
white
ZB 6
(see
info)
[mm]
[mm]
6.2 / 78.5 / 2
40.5 / 48
[A] / [mm ]
[kV] / –
–/–
2
32 / 6
8/3
III / I
[mm ]
[mm ]
[mm ]
[mm]
2
2
2
0.25 - 4
0.25 - 4
0.5-1
12
A4
PA
V0
130 / 120
)further
numbers of positions
see table 74/1.
Block diagram
Phoenix Contact Elektronischer Katalog
Page 2 / 2
