COMMUNICATIONS COMPONENTS
1510/1550 and 1550/1625 nm Filter Wavelength Division
Multiplexers
Key Features
• Thin film filter based
• Wide bandwidth
• Low insertion loss
• High isolation
• Low temperature dependent loss
• Epoxy-free optical path
Applications
• Network control applications
• Amplifier chain control
• Network protocol information
JDSU 1510/1550 and 1550/1625 filter wavelength division multiplexers use
interference filters to add a supervisory channel for active fiber monitoring.
Stable and reliable, filter WDMs have wide bandwidth, low insertion loss, high
isolation, and low temperature dependent loss.
Compliance
• Telcodia GR-1221
Performance for 1510/1550 nm (Model D1)
NORTH AMERICA
:
800 498-JDSU (5378)
WORLDWIDE
:
+800 5378-JDSU
WEBSITE
:
www.jdsu.com
1510/1550 AND 1550/1625 NM
FILTER WAVELENGTH DIVISION MULTIPLEXERS
2
Performance for 1550/1625 nm (Model E1)
ATTENUATION (dB)
35
30
0
25
20
0
15
10
REFLECT CHANNEL
0
PASS CHANNEL
5
0
1510 1540 1570 1600 1630 1660
WAVELENGTH (nm)
Specifications
Parameter
Pass 1510 /
Reflect 1550
1500 to 1520 nm
Maximum
Maximum
Minimum
1529 to 1565 nm
Maximum
Maximum
Minimum
Minimum
Minimum
Maximum
Maximum
Maximum
Maximum
Maximum
Pass 1550 /
Reflect 1510
Pass 1625 /
Reflect 1550
Pass 1550 /
Reflect 1625
1529 to 1565 nm
Pass port (C↔P) wavelength range
λ
P
Pass port (C↔P) insertion loss
Pass port (C↔P) flatness
Pass port (C↔P) isolation at
λ
R
Reflect port (C↔R) wavelength range
λ
R
Reflect port (C↔R) insertion loss
Reflect port (C↔R) flatness
Reflect port (C↔R) isolation at
λ
P
Directivity
Optical return loss
Polarization dependent loss
Polarization mode dispersion
Temperature dependent loss
Optical power
Tensile load
Operating temperature
Storage temperature
Package dimensions (D x L)
250 µm fiber
900 µm fiber
Fiber length
1529 to 1565 nm 1600 to 1650 nm
0.6 dB
0.3 dB
30 dB
1500 to 1520 nm 1529 to 1565 nm
0.4 dB
0.15 dB
12 dB
55 dB
50 dB
0.05 dB
0.1 ps
0.1 dB
500 mW
5N
-5 to 75°C
-40 to 85°C
1600 to 1650 nm
5.5 x 30 mm (Standard), 3.2 x 30 mm (Miniature)
5.5 x 40 mm (Standard), 3.2 x 40 mm (Miniature)
>1.0 m
1510/1550 AND 1550/1625 NM
FILTER WAVELENGTH DIVISION MULTIPLEXERS
Ordering Information
For more information on this or other products and their availability, please contact your local JDSU account manager or
JDSU directly at 1-800-498-JDSU (5378) in North America and +800-5378-JDSU worldwide or via e-mail at
customer.service@jdsu.com.
Sample: FWS-D10010000
FWS-
Code
D1
D2
E1
E2
00
Code
1
2
Fiber Type
250 µm fiber
900 µm fiber
Code
0
1
00
Package
Standard
Miniature
Code
0
1
2
3
4
5
6
Connector
1, 2
No connector
FC/SPC
FC/APC
SC/SPC
SC/APC
ST
LC/SPC
Wavelength
Pass 1510/Reflect 1550 (for 1510/1550nm)
Pass 1550/Reflect 1510 (for 1510/1550nm)
Pass 1625/Reflect 1550 (for 1550/1625nm)
Pass 1550/Reflect 1625 (for 1550/1625nm)
1. Connectors available only with 900 µm fiber option.
2. Other connectors available upon request.
NORTH AMERICA
:
800 498-JDSU (5378)
WORLDWIDE
:
+800 5378-JDSU
WEBSITE
:
www.jdsu.com
July 2008
Product specifications and descriptions in this document subject to change without notice. © 2008 JDS Uniphase Corporation 21021906 003 0708 WDMFILTER15101625.DS.CC.AE
SMF-28 is a registered trademark of Corning Incorporated. Telcordia is a registered trademark of Telcordia Technologies Incorporated.
